System Status; Mins - Delta Modulon DPH series User Manual

UPS-1.1
Power Flow
3
After selection of 'YES', the UPS will shut down each power module's output and let the
bypass AC source supply power. If the bypass AC source is abnormal, there is a risk of
output interruption and the connected critical loads won't be protected. At this moment,
each power module keeps charging the batteries, the tri-color LED indicator illuminates
yellow and the following screen appears (Figure 6-64). For the tri-color LED indicator
location, please refer to Figure 2-11.
UPS-1.1
Power Flow
Power Flow
Summary

System Status

4 Please log in as an Administrator. For the Administrator password, please contact
service personnel. After login, ensure that you are in the Administrator login status
(see Figure 6-65).
Modulon DPH Series
MEASUREMENT SETUP MAINTENANCE
POWER OFF ?
Transfer to Bypass without Protection!
Yes
(Figure 6-63: Power Off Reminder Screen)
MEASUREMENT SETUP MAINTENANCE
POWER FLOW
Maintenance
Bypass
Bypass
Mains
90 %

5 mins

(Figure 6-64: Bypass Mode Screen)
LOG IN EVENT LOG
User
No
LOG IN EVENT LOG
User
6-46
10:15
May 25,2018
Green
10:15
May 25,2018
Bypass
Load
30 %
