2.1

General Overview

The DPH series UPS, a three-phase four-wire online uninterruptible power supply, is a
dedicated design for data centers, factory facilities and large scale power systems. The
unit not only adopts advanced IGBT technology to provide high quality, low noise, pure and
uninterruptible output power to the connected loads, but also applies the latest design of DSP
digital control technology and highest quality components.
The UPS supports high efficient operation modes and its modular and hot-swappable design
makes maintenance easy and quick. You can add power modules (optional) according to
on-site applications to expand overall system capacity, which realizes a highly cost-effective
solution to your power requirements and produces greater electric power efficiency at less
cost.
The unit provides diversified communication interfaces and has built-in SNMP and MODBUS
cards for the user to facilitate remote control and management. You can parallel at maximum
eight UPS units to increase the system capacity and redundancy and enhance the unit's
availability and reliability.
2.2

Package Inspection

External
During UPS transportation, some unpredictable situations might occur. It is recommended
that you inspect the UPS exterior packaging. If you notice any damage, please immediately
contact the dealer from whom you purchased the unit.
Internal
1. Check the rating label attached to the UPS and make sure the device No. and capacity
match what you ordered.
2. Examine if any parts are loose or damaged.
3. The UPS package contains the following items. Please check if any items are missing.
Modulon DPH Series
1
2
6
11
3
7 8
×35 ×35
12 13
2-2
4 5
9
10
×35 ×10
14 15
×2
×2
