Delta Modulon DPH series User Manual page 150

6 Please log in as an Administrator. For the Administrator password, please contact
service personnel. After login, ensure that you are in the Administrator login status
(see Figure 6-41).
UPS-1.1
Power Flow
Power Flow
Summary
System Status
(Figure 6-41 : Main Screen_ Administrator Login & ON/ OFF Button Location)
7 Click SETUP
UPS-1.1
MODE SETTING
8
After manually selecting Energy Recycle mode via the LCD, press the icon (
located in the upper left corner of the screen to go back to the Main Screen.
9 Press the ON/ OFF button (
if you want to power on the UPS's inverter. Please select 'YES'.
Modulon DPH Series
MEASUREMENT SETUP MAINTENANCE
POWER FLOW
Maintenance
Bypass
Bypass
Mains
0 %
0 mins
Mode Setting
MEASUREMENT SETUP MAINTENANCE
Mode Setting
Select to change system mode
On-Line Green
(Figure 6-42: Select Energy Recycle Mode)
Administrator Login
2
LOG IN WARNING
Administrator
Energy Recycle.
2
LOG IN WARNING
Administrator
Energy Frequency
ECO
Recycle Conversion
) once and the following screen will pop up to ask you
