No.
1
2
(Built-in MODUBS card)
3
4
5
6
7
Modulon DPH Series
Item
RESET
MODBUS
BMS
DISPLAY
EMS/ CONSOLE
(USB Ports)
(Built-in SNMP card)
Description
Press the RESET button once to restart the LCD.
1. Lets the UPS have MODBUS communication
function.
2. Connects to a user-supplied monitoring system.
Connects to a user-supplied battery management
system or Delta battery management system
(optional).
1. Connects to the display port shown in Figure 4-3.
2. Before shipment, the display port has been
connected to the 10" touch panel with the
designated cable in Delta factory.
Connects to a user-supplied environmental monitoring
system or Delta EnviroProbe 1000/ 1100/ 1200
(optional).
There are two USB ports. Connect a user-supplied
USB flash drive to any of the USB ports to (1) upgrade
the UPS and LCD's firmware and (2) download event
logs.
1. Lets the UPS have network communication function.
2. Connects to a user-supplied monitoring system.
