Delta Modulon DPH series User Manual page 168

UPS-1.1
Power Flow
Power Flow
Summary
System Status
5 Click SETUP
UPS-1.1
MODE SETTING
6 Switch OFF the UPS's bypass switch (Q0) and Delta or non-Delta external maintenance
bypass cabinet's input breaker or switch (Q1).
7
The UPS will shut down, and then, the LCD and the tri-color LED indicator will be off.
Modulon DPH Series
MEASUREMENT SETUP MAINTENANCE
POWER FLOW
Maintenance
Bypass
Bypass
Mains
0 %
0 mins
(Figure 6-70 : Bypass Mode Screen_ Administrator Login)
Mode Setting
MEASUREMENT SETUP MAINTENANCE
Mode Setting
Select to change system mode
On-Line Green
(Figure 6-71: Select On-Line Mode)
Administrator Login
2
LOG IN WARNING
Administrator
On-Line.
2
LOG IN WARNING
Administrator
Energy Frequency
ECO
Recycle Conversion
6-50
10:15
May 25,2018
Bypass
Load
0 %
10:15
May 25,2018
Bypass
