Delta Modulon DPH series User Manual page 87

1 Unscrew the eight M5 screws to remove the rear panel (see Figure 5-5 and Figure
5-6). After removing the real panel, you will see the AC Input terminals and Bypass Input
terminals shown in Figure 5-7.
(Rear)
(Figure 5-5: UPS Rear View)
(Rear View after Rear Panel Removal)
32
32
BYPASS I/P T BYPASS I/P S BYPASS I/P
22 21
(Figure 5-7: Wiring Terminals_ AC Input & Bypass Input)
(Figure 5-6: Rear Panel & Screw Location)
32 32 32
32
35
R BYPASS I/P N MAIN I/P N MAIN I/P T MAIN I/P R
22 21 22 21
5-11
(Rear)
Bypass Input Terminals
T R
S
N N
32 32
32
T S R
BYPASS I/P BYPASS I/P BYPASS I/P BYPASS I/P N MAIN I/P
5 Installation and Wiring
M5 Screw X 8
Rear Panel
AC Input Terminals
T R
S
32 32
32
35
N T R
MAIN I/P MAIN I/P
