Delta Modulon DPH series User Manual page 162

UPS-1.1
Power Flow
Power Flow
Summary
System Status
5 Click SETUP
the UPS will run in bypass mode to let the bypass AC source supply power to the
output.
UPS-1.1
MODE SETTING
6
Single Input:
Switch OFF the UPS's bypass switch (Q0) and Delta or non-Delta external maintenance
bypass cabinet's input breaker or switch (Q1).
Dual Input:
Switch OFF the UPS's bypass switch (Q0), Delta or non-Delta external maintenance
bypass cabinet's input breaker or switch (Q1) and bypass breaker or switch (Q2).
Modulon DPH Series
MEASUREMENT SETUP MAINTENANCE
POWER FLOW
Maintenance
Bypass
Bypass
Mains
90 %
5 mins
(Figure 6-60 : Standby Mode Screen_ Administrator Login)
Mode Setting
MEASUREMENT SETUP MAINTENANCE
Mode Setting
Select to change system mode
On-Line Green
(Figure 6-61: Select On-Line Mode)
Administrator Login
LOG IN EVENT LOG
Administrator
On-Line. If the bypass voltage is in the normal range,
LOG IN EVENT LOG
Administrator
Energy Frequency
ECO
Recycle Conversion
6-44
10:15
May 25,2018
Standby
Load
0 %
10:15
May 25,2018
Bypass
