Unipulse F370 Operation Manual

Unipulse F370 Operation Manual

Digital indicator
Hide thumbs
Table of Contents

Advertisement

Quick Links

F370
DIGITAL INDICATOR
　　　　　　　　　　　
　　　　　
OPERATION MANUAL
20 Jul. 2011
Rev. 1.19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F370 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Unipulse F370

Summary of Contents for Unipulse F370

  • Page 1 F370 DIGITAL INDICATOR 　　　　　　　　　　　 　　　　　 OPERATION MANUAL 20 Jul. 2011 Rev. 1.19...
  • Page 2 - Where the product may be splashed with water, oil or chemicals. - Where the main body is directly affected by vibration or shock. ● Set the correct Excitation Voltage for the sensor. （2.5V is set when F370 is dispatched from us.）...
  • Page 3 Safety Precautions ● Indications for safe use and their meanings In this manual, precautions for using the F370 digital indicator safely are indicated as follows. Be sure to follow the precautions given here because they are important descriptions relating to safety.
  • Page 4 Safety Precautions ● About the built-in lithium battery WARNING Never disassemble, deform under pressure or throw the battery into fire.The battery may explode, catch fire or leak. - Battery Model: CR2477-1HF made by Matsushita Battery Industrial Co., Ltd. Nominal voltage: 3V Nominal electric capacity: 1000mAh ●...

  • Page 5: Table Of Contents

    2．SETTING MODES ........5 2-1．F370 Screen Configuration ....... .5 2-2．Setting Modes Tree .
  • Page 6 CONTENTS 4-5．Equivalent Input Calibration .......19 4-6．Digital Offset ......... .21 4-7．Increment (This step may be omitted if there is no change.) .
  • Page 7 CONTENTS 7．HOLD FUNCTIONS ....... . .44 7-1．Hold Setting --- common --- ......44 7-1-1．Hold Mode .
  • Page 8 CONTENTS 9．WAVEFORM DISPLAY ......67 9-1．Graphic Display Screen ........67 9-1-1．Hold Point Plotting .
  • Page 9 CONTENTS 11-2．RS-232C Interface Setting .......81 11-2-1．Communication Mode ......... . 81 11-2-2．Baud Rate .
  • Page 10 CONTENTS 16．SELF-CHECK AND INITIALIZATION ....101 16-1．Self-Check ......... .101 16-1-1．Self-Check DSP .
  • Page 11 CONTENTS...

  • Page 12: 1．Appearance Description

    This is the touch panel display for displaying an indicated value and graph set value and for setting various setting items of the F370. During measurement, a comparison display, hold display and graph display can be selected according to the function in use.

  • Page 13: Rear Panel

    1.APPEARANCE DESCRIPTION 1-2. Rear Panel AC power source Signal I/O terminal input terminal block block Frame ground Optional slot 1-2-1. Signal I/O Terminal Block Pin assignments ST/SP CODE2 CODE3 CODE0 CODE1 COM2 ※ COM1 ※ -EXC -SIG +EXC +SIG...
  • Page 14 The graphic display start/stop signal. → page69「Graph Plotting」 See the section on External I/O Connection page 12 for connection. SI/F The 2-wire serial interface for coupling a UNIPULSE printer, external display, etc. See the section on SI/F Connection page 11 for connection. Caution Use TMEV1.25-3S crimp contacts (attached) made by NTM or...

  • Page 15: Ac Power Source Input Terminal Block

    1.APPEARANCE DESCRIPTION 1-2-2. AC Power Source Input Terminal Block Connect the AC power cord. The input voltage is 100V - 240V AC, and the frequency is 50/60Hz. 1-2-3. Frame Ground (Functional ground) This is a ground terminal block. Be sure to ground the F.G. terminal to prevent electric shocks and failures due to static electricity.

  • Page 16: 2．Setting Modes

    2.SETTING MODES 2. SETTING MODES 2-1. F370 Screen Configuration [Ordinary display screen] MODE Set value entry from the ordinary display screen HOME [Mode selection screen] Mode keys [Set value selection screen] HOME Setting keys [Set value entry screen] HOME With the NEXT key on the set value entry screen, the next set value entry screen appears.

  • Page 17: Setting Modes Tree

    2.SETTING MODES 2-2. Setting Modes Tree ordinary display screen Mode selection screen OPERATION COMPARISON HOLD GRAPH PAGE1 PAGE1 PAGE1 PAGE1 Digital Filter (P29) HI_HI Limit (P38) Hold Function (P44) Graph Function (P72) Analog Filter (P30) HI Limit (P38) Hold Detect Time (P45) Interval Time (P72)
  • Page 18 2.SETTING MODES CALIBRATION OPTION SYSTEM PAGE1 PAGE1 Zero Cal. (P17) All Para. Clear (P103) Actual Cal. (P18) A setting function changes SelfCheck DSP (P101) Equiv. Cal. (P19) by the option. SelfCheck MEM (P101) CAL. Select (P25) SelfCheck KEY (P102) Increment (P22) SelfCheck EXT (P102)

  • Page 19: About A Setting Call

    2.SETTING MODES 2-3. About a Setting Call In this manual, a setting function call is described as follows. Calibration Protection Operation setting Page 3 Setting call → → ↑ ↑ Mode Page This call can be made by the following procedure. 1）Press the MODE button on the ordinary display screen.

  • Page 20: 3．Connection

    Connect the positive (+) side of the power source to the red screw side of the terminal block on the back of the F370, and its negative (-) side to the black screw side. The input voltage is 12V - 24V DC.

  • Page 21: Load Cell Connection

    3.CONNECTION 3-2. Load Cell Connection ・4-wire sensor （+EXC） （-SIG） +OUT -OUT F370 （-EXC） （+SIG） （F.G or ） ・6-wire sensor Short-circuit +EXC with +S and -EXC with -S for connecting a 6-wire strain-gage sensor. （+EXC） （-SIG） -OUT +OUT F370 （-EXC） （+SIG）...

  • Page 22: Si/F Connection

    3.CONNECTION 3-3. SI/F Connection The 2-wire serial interface has connective ability for coupling a UNIPULSE printer, external display, etc. The interface is nonpolarized and up to three external instruments may be connected. A two-core parallel cable or a cabtyre cable may be used for connection.

  • Page 23: External I/O Connection

    The external output circuit is operated through an open collector. A3 COM1 is the common terminal. The open collector output capacity is 30mA and the withstand voltage is up to 30V. ・ Equivalent circuit Vext F370 Inside Spark Killer Power Supply Load Relay...

  • Page 24: Connecting To Cage Clamp Terminal Block

    3.CONNECTION 3-4-3. Connecting to Cage Clamp Terminal Block The output terminal D/A option and RS-485 option is using the cage clamp system terminal stand. Please connect in the following procedure. 1.Strip the casing 0.2inch (6mm) on the cable to be connected. 5 - 6mm 2.Twist the bare wire to fit the terminal hole.

  • Page 25: 4．Calibration

    4.CALIBRATION 4. CALIBRATION Calibration is performed for matching the F370 to a strain-gage sensor. The following two types of calibration are available for the F370. ◇ Equivalent Input Calibration Calibration is performed without an actual load by entering the rated output value (mV/ V) and the capacity (to be indicated) of the strain-gage sensor by the keys.

  • Page 26: Equivalent Input Calibration Procedure

    4.CALIBRATION ◇ Actual Load Calibration Apply an actual load to the strain-gage sensor and enter the actual load value by the keys for calibration. Calibration is accurately performed with reductions in errors. F370 Actual load Strain gauge sensor Indicated value 4-1.

  • Page 27: Actual Load Calibration Procedure

    4.CALIBRATION 4-2. Actual Load Calibration Procedure Follow the steps below to perform equivalent input calibration. 4-9. Calibration Release the calibration protection. Protection Release Set the calibration value No. 4-10. Calibration (This step may be omitted for use with only one Value Selection selection.) 4-7.

  • Page 28: Zero Calibration

    4.CALIBRATION 4-3. Zero Calibration Set the zero point in no-load condition. How to set Setting call Page 1 → Calibration → 1）Press the MODE button. 2）Press the CALIBRATION button. 3）Press the Zero Cal. button. 4）Press OK button after confirming no-load was applied to the sensor.

  • Page 29: Actual Load Calibration

    4.CALIBRATION 4-4. Actual Load Calibration Set the actual load value under an actual load. How to set Calibration Setting call Page 1 → → 1）Press the MODE button. 2）Press the CALIBRATION button. 3）Press the Actual Cal. button. 4）Apply an actual load to the sensor, enter the actual load value by the numerical keys and determine with the OK button.

  • Page 30: Equivalent Input Calibration

    4.CALIBRATION 4-5. Equivalent Input Calibration Set the rated output value and reading of the sensor. Rated output value: 0.000 - 3.000mV/V Rated value: 00000 - 99999 How to set Calibration Setting call Page 1 → → 1）Press the MODE button. 2）Press the CALIBRATION button.
  • Page 31 4.CALIBRATION 4） Enter the rated output of the sensor by the numerical keys and determine with the OK button. The decimal point is fixed. 5）Enter the rated value by the numerical keys and determine with the OK button.

  • Page 32: Digital Offset

    4.CALIBRATION 4-6. Digital Offset By using the digital offset function, the value obtained by subtracting the set value from the indicated value is displayed. This function is convenient when zero cannot be obtained with no load for some reason or for offsetting. (displayed value)=(actual indicated value)-(offset value) Setting range －...

  • Page 33: Increment (This Step May Be Omitted If There Is No Change.)

    4.CALIBRATION 4-7. Increment (This step may be omitted if there is no change.) Set the increment of the indicated value. Input range: 001 - 100 How to set Calibration Setting call Page 1 → → 1）Press the MODE button. 2）Press the CALIBRATION button. 3）Press the INCREMENT button.

  • Page 34: Decimal Place

    4.CALIBRATION 4-8. Decimal Place Set the decimal point place of the indicated value. Selection can be made from the following. 0, 0.0, 0.00, 0.000, 0.0000 How to set Calibration Setting call Page 2 → → 1）Press the MODE button. 2）Press the CALIBRATION button. 3）Press the PAGE button to select the page and press the DECIMAL PLACE button.

  • Page 35: Calibration Protection

    4.CALIBRATION 4-9. Calibration Protection Calibration-related set values can be protected so that they will not be changed by misoperation. When Cal. Protect is ON, no change can be made while the alarm sounds. ON: Protected OFF: Unprotected How to set Calibration Setting call Page 3...

  • Page 36: Calibration Value Selection

    4.CALIBRATION 4-10. Calibration Value Selection By storing up to four calibration values in the memory, the desired calibration value can be called to switch the indicated value. Setting values that can be switched are as follows: Calibration Mode Setting Operation Mode Setting Zero Calibration Excitation Voltage Actual Load Calibration...
  • Page 37 4.CALIBRATION 3）Press the CAL. SELECT button. 4）Select the calibration value from 0 - 3 and determine with the OK button.

  • Page 38: Unit

    4.CALIBRATION 4-11. Unit Set the unit of the load to be displayed. Selection can be made from the following. None, kg, g, t, N, kN, Nm, N/m , Pa, kPa, MPa, bar How to set Calibration Setting call Page 2 →...

  • Page 39: 5．Setting Of Functions

    5.SETTING OF FUNCTIONS 5. SETTING OF FUNCTIONS 5-1. Digital Zero This function zeros the value currently indicated. Digital Zero by key input 1） Press the DZ button on the ordinary display screen. 2） Digital Zero is activated by pressing OK button then indicated value becomes 　...

  • Page 40: Digital Filter

    5.SETTING OF FUNCTIONS 　 Digital Zero conducted by External signal (D/Z input) Digital Zero activates in the moment when the connection of the external input terminal D/Z on the rear panel and COM2 is switched from Open to Short-circuit then the indicated value becomes Zero. Keep on for 1.0 msec.

  • Page 41: Analog Filter

    5.SETTING OF FUNCTIONS 5-3. Analog Filter A low-pass filter is provided for filtering input signals from the strain-gage sensor and canceling noise components. The cut-off frequency can be selected in a range between 10Hz and 300Hz. With an increase in the cut-off frequency, the response becomes faster, but noise components may be indicated.

  • Page 42: Stability

    5.SETTING OF FUNCTIONS 5-5. Stability Enter the parameters to detect stability. If the difference between the current indicated value and the 50-msec-previously indicated value is less than the set count and the duration of the condition is more than the set time, the indicated value is regarded to be stable. When stability is detected, a digital filter (fixed 16 times) to control instability in weight value is automatically inserted.

  • Page 43: Zero Track

    5.SETTING OF FUNCTIONS 5-6. Zero Track Gradual changes in the zero point due to drifts etc., are automatically tracked for correction. ・When displacement of the zero point is within the set count of tracking and it continues more than the set time, it is automatically made zero by Zero Tracking function.

  • Page 44: Contrast Adjustment

    5.SETTING OF FUNCTIONS 5-7. Contrast Adjustment Adjust the contrast of the touch panel display. Brightness can be adjusted by CONTRAST1. Screen flickering can be adjusted by CONTRAST2. How to set Setting call Operation Setting → Page 2 → 5-8. Backlight The backlight is turned off if no button operation is performed for the set time (minutes).

  • Page 45: Auto Print

    5-10. Auto Print The indicated value is automatically printed to the UNIPULSE printer coupled with the F370 through the SI/F. A print is made when the indicated value is stable. (Set the stability parameters by the stability operation.) When Near Zero is OFF, Indicated value is held until Near Zero turns ON after Stability turned ON.
  • Page 46 5.SETTING OF FUNCTIONS Time Near Zero Indicated Value Sensor input value － Stable Near Zero 1.5Seconds Hold ↑ Autmatic Printing Auto Print is not performed under the following conditions. ・Motion Detect 　Time: 0.0 sec. Width: 0.0 of divisions is set. ・Print while hold is released.

  • Page 47: Hold Off Print

    5.SETTING OF FUNCTIONS 5-11. Hold Off Print At hold-off time, the held value is automatically printed to the UNIPULSE printer coupled with the F370 through the SI/F. (The hold is released by the T/H signal off timing when the period setting is all interval in various hold modes by hold functions, and by the T/H signal of timing when other periods are set.)

  • Page 48: 6．Comparison Functions

    6.COMPARISON FUNCTIONS 6. COMPARISON FUNCTIONS By the comparison function, the HI limit and LO limit values are set, and when the indicated value exceeds the HI limit, the HI output is turned on, and when the indicated value falls below the LO limit, the LO output is turned on. Also, HI-HI limit and LO-LO limit values may be set outside the HI-LO limit comparison.

  • Page 49: Hi Limit/Lo Limit/Hi-Hi Limit/Lo-Lo Limit

    6.COMPARISON FUNCTIONS 6-1. HI Limit/LO Limit/HI-HI Limit/LO-LO Limit How to set Comparison setting Setting call Page 1 → → Simple setting call Press any of the HI-HI, HI, LO and LO-LO buttons at the bottom of the indicated value display screen to go direct to the entry screen. About the indicated value display color The display color can be changed by pressing the indicated value display section.

  • Page 50: Hysteresis

    6.COMPARISON FUNCTIONS 6-2. Hysteresis The hysteresis value may be determined so as to allow a margin for timing the turning off of the HI-LO limit comparison. Normally, it is turned on when the indicated value exceeds the HI limit and is turned off when the indicated value falls below it. However, by setting the hysteresis, it is turned off when the indicated value falls below the HI limit further lowered by the hysteresis value.
  • Page 51 6.COMPARISON FUNCTIONS ・ Hysteresis operation Indicated Value HI Limit Value Hysteresis Range LO Limit Value ＋ － Time HI Output HI Status Display Output OFF Output OFF Output ON Status OFF Status OFF Status ON LO Output LO Status Display Output OFF Output ON Output ON...

  • Page 52: Near Zero

    6.COMPARISON FUNCTIONS 6-3. Near Zero By this function, it is detected that the indicated value is near zero. Near-zero ON: indicated value <=near zero set value Near-zero OFF: indicated value > near zero set value Setting range: 00000 - 99999 Turning on/off the near zero function is closely related to the auto print function and HI-LO limit comparison.

  • Page 53: Hi-Lo Limit Output Mode

    6.COMPARISON FUNCTIONS 6-5. HI-LO Limit Output Mode The number of HI-LO limits can be changed. Mode HI Limit Operation LO Limit Operation Mode 0 None HI-HI Limit，HI Limit， LO Limit，LO-LO Limit Mode 1 LO-LO Limit HI-HI Limit，HI Limit， LO Limit Mode 2 HI-HI Limit，HI Limit LO Limit，LO-LO Limit...

  • Page 54: Alarm Mode

    6.COMPARISON FUNCTIONS 6-6. Alarm Mode The comparison target of the HI-HI limit and LO-LO limit set values can be changed from “hold value” to “real-time value”. By this function, whether or not the indicated value becomes abnormal during hold can be monitored. Unavailable : Comparison operation is performed with hold values.

  • Page 55: 7．Hold Functions

    7-1. Hold Setting --- common --- 7-1-1. Hold Mode The F370 includes nine hold modes as shown in the table below. In the peak, valley, peak-to-peak and mean value modes, period setting is required. Select all period, external signal, time, or time with trigger.

  • Page 56: Hold Detection Time

    7.HOLD FUNCTIONS Simple setting call Press the MODE button at the bottom of the indicated value display screen to go direct to the hold mode entry screen. 7-1-2. Hold Detection Time If you set the hold period setting in the hold function setting to Time or Time with Trigger, set the time.

  • Page 57: Auto Start Level

    7.HOLD FUNCTIONS 7-1-3. Auto Start Level If you select the time specified period mode with trigger, or relative maximum, relative minimum or inflection point hold in the hold mode setting, set the start level. Setting range: -99999 - 99999 How to set →...

  • Page 58: Hold Setting

    7.HOLD FUNCTIONS 7-2. Hold Setting --- relative maximum and relative minimum --- If you select the relative maximum and relative minimum hold in the hold function setting, set the relative maximum and relative minimum value detection parameters "minimum count" and "valley detection level". Set referring to the principle of operation only when the value cannot be held successfully with the factory settings or when further adjustments are required.

  • Page 59: Minimum Count

    7.HOLD FUNCTIONS 7-2-1. Minimum Count Setting range: 0001 - 9999 How to set Setting call → Page 1 Hold → 7-2-2. Valley Detection Level Level: 1/4, 1/2, 3/4, 1, 1.25, 1.5, 2, 3 times How to set Setting call → Page 1 Hold →...

  • Page 60: Hold Setting

    7.HOLD FUNCTIONS 7-3. Hold Setting --- inflection point --- If you select the inflection point hold in the hold function setting, set the inflection point detection parameters "minimum slope", "interval A" and "interval B". Set referring to the principle of operation only when the value cannot be held successfully with the factory settings or when further adjustments are required.

  • Page 61: Minimum Slope

    Page 2 Hold → The interval setting is the number of samplings. Since the F370's sampling speed is 2000 times/sec., one sampling is 0.5msec. Therefore, setting of the interval at 100 means setting of 50msec. Caution regarding inflection point hold...
  • Page 62 7.HOLD FUNCTIONS Example of inflection point hold setting ● Example of ideal waveform setting D = 80 C = 10 100msec 100msec ① Set the load change time (between the inflection point and when the change stops) to interval B. In the example, it is set to 200 since it is 100 msec.

  • Page 63: Hold Setting

    7.HOLD FUNCTIONS 7-4. Hold Setting --- mean value --- 7-4-1. Mean Value Sampling Count If the mean value sampling count is set at 2 or more in the mean value hold, the representative value of the sampling values by the set count (mean value by the count) is adopted as the sampling data used for mean value calculation.

  • Page 64: Hold Operation

    7.HOLD FUNCTIONS 7-5. Hold Operation 7-5-1. Sample Hold When the T/H signal is inputted, a desired point is held, and the H/E output is turned on. Hold of the value continues as long as the T/H signal is on. ＋ Sensor Input Value Indicated Value Detection ・...

  • Page 65: Peak Hold

    7.HOLD FUNCTIONS 7-5-2. Peak Hold The maximum value (peak) in the positive direction of the specified period is held. The period is specified by the setting of “all period”, “external signal”, “time”, or “time with trigger”. (Example) All Period Peak Hold ＋...

  • Page 66: Valley Hold

    7.HOLD FUNCTIONS 7-5-3. Valley Hold The maximum value (valley) in the negative direction of the specified period is held. The period is specified by the setting of “all period”, “external signal”, “time”, or “time with trigger”. (Example) All Period Valley Hold ＋...

  • Page 67: Peak-To-Peak (P-P) Hold

    7.HOLD FUNCTIONS 7-5-4. Peak-to-Peak (P-P) Hold The maximum value of the difference between the peak and valley over the specified period is held. The period is specified by the setting of “all period”, “external signal”, “time”, or “time with trigger”. (Example) All Period Peak-to-Peak (P-P) Hold ＋...

  • Page 68: Relative Maximum And Relative Minimum Hold

    7.HOLD FUNCTIONS 7-5-5. Relative Maximum and Relative Minimum Hold Detection starts when the indicated value crosses the auto start level with the H/M signal inputted. Detection is performed as long as the H/M signal is on. The hold is released by turning on the T/H signal as a reset signal. The H/E output signal is on between the instant when the hold starts and the instant when the T/H signal is turned on.
  • Page 69 7.HOLD FUNCTIONS The Hold Function in General The delay times of the judging signal and the H/E signal do not include a ● delay time of the analog circuit (low-pass filter). Also, the delay times are calculated without the digital filter. Since the judging signal and the H/E signal are generated for the value produced through the analog and digital filters, transmission of the signals becomes slower and the delay of each output signal increases with enhancement of the filters.

  • Page 70: Inflection Point Hold

    7.HOLD FUNCTIONS 7-5-6. Inflection Point Hold Detection starts when the indicated value crosses the auto start level with the H/M signal inputted. Detection is performed as long as the H/M signal is on. The hold is released by turning on the T/H signal as a reset signal. The H/E output signal is on between the instant when the hold starts and the instant when the T/H signal is turned on.

  • Page 71: Mean Value Hold

    7.HOLD FUNCTIONS 7-5-7. Mean Value Hold The mean value of the sampling values over the specified period is calculated and updated to perform comparison operation. The period is specified by the setting of “all period”, “external signal”, “time”, or “time with trigger”.

  • Page 72: How To Specify The Hold Detection Period

    7.HOLD FUNCTIONS 7-6. How to Specify the Hold Detection Period 7-6-1. All Period By this method, the hold detection period is externally specified by the T/H signal. Detection starts with the T/H signal ON to perform each hold operation. Detection ends with the T/H signal OFF to reset the hold. (Example) All Period Peak Hold ＋...

  • Page 73: Externally Specified Period Hold

    7.HOLD FUNCTIONS 7-6-2. Externally Specified Period Hold (Peak, Valley, Peak-to-Peak and Mean Value) By this method, the hold detection period is externally specified by the H/M signal to maintain the hold value until the reset signal is turned on. The hold is released by turning on the T/H signal as a reset signal. The H/E output signal is on between the instant when the H/M signal is turned off and the instant when the T/H signal is turned on.

  • Page 74: Time Specified Period Hold

    7.HOLD FUNCTIONS 7-6-3. Time Specified Period Hold (Peak, Valley, Peak-to-Peak and Mean Value) Hold is detected during the predetermined time (hold detection time) from the point in time when the H/M signal is turned on. The hold is released by turning on the T/H signal as a reset signal.

  • Page 75: Time Specified Period Hold With Trigger

    7.HOLD FUNCTIONS 7-6-4. Time Specified Period Hold with Trigger (Peak, Valley, Peak-to-Peak and Mean Value) Hold is detected during the predetermined time (hold detection time) from the point in time when the indicated value crosses the auto start level. The hold is released by turning on the T/H signal as a reset signal.

  • Page 76: 8．Multi-Hold Function

    8.MULTI-HOLD FUNCTION 8. MULTI-HOLD FUNCTION By this function, up to 16 types of hold and comparison set values can be stored and selected with external switching signals of CODE0 - CODE3. Normally, if there is no entry for CODE0 - CODE3, the set value of CH0 is selected, but when CODE0 - CODE3 are in the following conditions, the set value of each setting CH is selected.

  • Page 77: About Changing Of The Setting Ch

    8.MULTI-HOLD FUNCTION 8-1. About Changing of the Setting CH When changing the hold or comparison set value of each CH, set the CH No. with the CH change key on the mode selection screen, and change the set value. How to set 1）Select the setting CH on the mode setting screen.

  • Page 78: 9．Waveform Display

    9.WAVEFORM DISPLAY 9. WAVEFORM DISPLAY 9-1. Graphic Display Screen Graph is updated while usually operating on the display screen (a comparison ,a hold ,graph ). Indicated value display(At cursor ON time, the cursor 　　　　　　　　　　point (green) value is displayed.) Y-axis (load axis) X-axis (time axis) Graphic display START/STOP Cursor move keys (The cursor moves on the X-axis.)

  • Page 79: Hold Point Plotting

    9.WAVEFORM DISPLAY 9-1-1. Hold Point Plotting By using the hold function and the graph plotting function together, the held point (red) can be plotted. Example) Relative maximum hold Held point 9-1-2. X-axis and Y-axis on the Graph Plotting Screen X-axis The X-axis is a time setting axis.

  • Page 80: Graph Plotting

    9.WAVEFORM DISPLAY 9-2. Graph Plotting 9-2-1. Continuous Graph plotting is started by turning on the START/STOP key or turning on the ST/SP external input. When it ends on one screen, the screen is cleared after expiration of the interval time and graph plotting restarts on the next screen. It is ended by turning off the START/STOP key or turning off the ST/SP external input.

  • Page 81: External

    9.WAVEFORM DISPLAY 9-2-2. External Plotting is started by turning on the START/STOP key or turning on the ST/SP external input. Plotting ends on one screen at the predetermined time of the X end point. ＋ START/STOP （Key） ST/SP （Outside Input） 1.0msec more Plotting Period...

  • Page 82: Level

    9.WAVEFORM DISPLAY 9-2-3. Level Plotting is started when the conditions of the detection mode are met in comparison of the trigger level set value and indicated value. Plotting ends on one screen at the predetermined time of the X end point. ＋...

  • Page 83: Graph Function

    9.WAVEFORM DISPLAY 9-3. Graph Function Set the graph plotting mode. Modes Continuous, external, level, external + level How to set Setting call → Page 1 Graph → 9-4. Interval Time If you select "continuous" in the graph function setting, set the graph plotting operation interrupting time from clearing the screen until moving to the next graph plotting operation.

  • Page 84: Level Detection Mode

    9.WAVEFORM DISPLAY 9-6. Level Detection Mode If you select [level] or [external + level] in the graph function setting, set the graph plotting start level comparison conditions. Conditions: passing, passing over, passing under, large, small How to set Setting call →...

  • Page 85: Start Point

    9.WAVEFORM DISPLAY 9-7. X Start Point Set the time to display by one screen in the range between 0.1 sec. and 99.9 sec. How to set Setting call → Page 1 Graph → Simple setting call Press the X button on the graph display to go direct to the X end point entry screen. 9-8.

  • Page 86: 10．Bcd Data Output(Option)

    10.BCD DATA OUTPUT(OPTION) 10. BCD DATA OUTPUT(OPTION) The BCD data output is an interface to extract the indicated value of the F370 as BCD data. This interface is convenient to process controls, totals, records, etc., by connecting the F370 to a computer, process controller, sequencer or the like.

  • Page 87: Logic Change

    When COM and pin No. 27 are open: hold cancel When they are short-circuited: hold on 10-4. Equivalent Circuit ・Output The signal output circuit is operated through a TTL open collector. Vext F370 Inside Outside Vceo=30V(max) Ic =30mA (max) ● Internal transistor status ●...

  • Page 88: Signal Timing

    10.BCD DATA OUTPUT(OPTION) ・Input Open OFF F370 Short ON Inside Outside Transistor IC=Approx.6mA Switch TTL open collector output (ON when IN is HI) NOTE - Do not apply external voltage to the signal input circuit. - The external element is required to withstand Ic=10mA.

  • Page 89: Bcd Data Update Rate Selection

    10.BCD DATA OUTPUT(OPTION) ・STROBE Strobe pulses are outputted in synchronization with BCD data. Read data using the rising edges of the pulses. The BCD data update rate setting can be changed. BCDdata OVER STROBE Storobe range 10-6. BCD Data Update Rate Selection Output rate: 1, 10, 100, 1000 times How to set Setting call...

  • Page 90: 11．Rs-232C Interface(Option)

    11.RS-232C INTERFACE(OPTION) 11. RS-232C INTERFACE(OPTION) RS232C 11-1. Communication Specifications 11-1-1. Specifications Signal level： Based on RS-232C Transmitting distance ： Approx.15m Transmitting method ： Asynchronous，Full duplex Transmitting speed ： 1200，2400，4800，9600 or 19200bps Selectable Bit configuration ： Start bit 1bit Character length 7 or 8 bit Selectable Stop bit 1 or 2 bit Selectable...

  • Page 91: Connector Pin Assignment

    11.RS-232C INTERFACE(OPTION) 11-1-2. Connector Pin Assignment Adaptable plug： 25-pin D-sub connector（JAE make DB-25P-N etc） ＊ ＊ 11-1-3. Cable F370 PC etc ・ ・ ・ Cross Cable TｘD TｘD RｘD RｘD (CD) (DSR) * This connection diagram shows an example of connecting a DTE (data terminal equipment) personal computer.

  • Page 92: Rs-232C Interface Setting

    11.RS-232C INTERFACE(OPTION) 11-2. RS-232C Interface Setting Set the RS-232C communication conditions of the F370. 11-2-1. Communication Mode Communication mode 0, communication mode 1, communication mode 2 How to set Setting call → Page 1 Option → 11-2-2. Baud Rate 1200，2400，4800，9600，19200bps...

  • Page 93: Stop Bit

    11.RS-232C INTERFACE(OPTION) 11-2-5. Stop Bit 1 bit, 2 bit How to set Setting call → Page 1 Option → 11-2-6. Terminator CR，CR ＋ LF How to set Setting call → Page 2 Option → 11-3. Communication Modes 1.Communication Mode 0 Communications are carried out by commands from the host computer.

  • Page 94: Communication Format

    11.RS-232C INTERFACE(OPTION) 11-4. Communication Format 1. Communication Mode 0 - Reading the indicated value (sign, 5-digit indicated value, decimal point) Host A CR ＋ F370 Terminator - Reading the status (7-digit) Host D CR F370 Terminator 1:ON ※ Undefined Hold...
  • Page 95 11.RS-232C INTERFACE(OPTION) - Writing parameters （Set Value HI-HI Limit ± Lock) （Set Value HI limit ± Lock) （Set Value LO limit CR LF ± Lock) （Set Value LO-LO Limit CR LF ± Lock) Hysteresis （Set Value CR LF Lock) Calibration Value （Calibrationt Value ⑥...
  • Page 96 11.RS-232C INTERFACE(OPTION) Graph Function ④ Interval Time （Set Value CR LF Graph Start Level Lock) （Set Valu Level Detect Mode CR LF ⑤ Lock) CR LF Hold Point Shift...
  • Page 97 11.RS-232C INTERFACE(OPTION) Set value correspondence table ① Hold mode 0： tracking 5： relative maximum 1： sample 6： relative minimum 2： peak 7： inflection point 3： valley 8： mean value 4： peak-to-peak ② Hold period setting 0： all period 1： external signal 2：...
  • Page 98 11.RS-232C INTERFACE(OPTION) - Reading waveform data Host ± F370 …… 00 ～ 19 Data Section No. 00 ～ 19 Decimal Point and Five digits Data1 Data Section No. ± ± …… Terminator Decimal Point and Five digits Data9 Decimal Point and Five digits Data10 ・Wave form hold point data read-out(data No, a mark, a decimal point,5 figures of...
  • Page 99 Ｗ F370 Terminator Set Value No. Set Value No. The same format as write-in of set values. - Commands (Host → F370) Digital Zero （This is effctive only when the set value Ｃ LOCK is "1."） Digital Zero reset Ｃ...
  • Page 100 11.RS-232C INTERFACE(OPTION) ＊ 1 O..Over Load（LOAD，OFL） S ..Stable M..Not Stable H..Hold ＊ 1Priority H ＞ O ＞（Ｓ or Ｍ） ＊ 2 A..Zero Tracking OFF T ..Zero Tracking ON ＊ 3 H..High Limit ON L ..Low Limit ON G..High Limit and Low Limit OFF N..High Limit and Low Limit ON F ..Compare OFF...

  • Page 101: 12．Rs-485 Communication Interface(Option)

    Set the communications mode of the F370 to “4-wire.” Connect the “SD” (sending side) of the equipment on the other end (master), such as a programmable controller, to “RD” (receiving side) of the F370 (slave), and “RD” of the master to “SD” of the F370.
  • Page 102 Couple a terminal resistor of 100 - 200Ω to the receiving end. (The terminus resistance by the side of F370 can be switched by setup.120 ohms is conncted when terminus resistance is set as ON.)
  • Page 103 （Master） 2. Polarity Basically, connect “A” or “-” of the equipment on the other end to “A-” of the F370, and “B” or “+” of the equipment on the other end to “B+” of the F370. (In some rare cases, the signal polarity (A/B notation) may be reversed, so that communications cannot be made even with correct connection.

  • Page 104: Communication Method

    12.RS-485 COMMUNICATION INTERFACE(OPTION) 12-3. Communication Method 1． For connecting more than one F370, assign an ID number to each F370. 2．Send the start command including the ID number from the host, whereby communications are allowed with one F370, enabling reading of indicated value, reading and changing of set values (parameters), sending of commands and so on.

  • Page 105: Interface Setting

    12.RS-485 COMMUNICATION INTERFACE(OPTION) 12-4. RS-485 Interface Setting 12-4-1. ID Setting range: 0000 - 9999 How to set Setting call → Page 2 Option → 12-4-2. Terminator Resistance Without terminator resistance / with terminator resistance How to set Setting call → Page 2 Option →...

  • Page 106: 13．D/A Converter(Option)

    -10 - 10V and 4 - 20mA can be obtained between VOL and G and between CUR and G, respectively. - Taking voltage output signals Connect external equipment (2KΩ or more load resistance) to VOL and G of the F370. F370 ← Inside Outside → ＋...

  • Page 107: Voltage Zero And Full Scale, Current Zero And Full Scale

    13.D/A CONVERTER(OPTION) - Taking current output signals Connect external equipment (350Ω or less load resistance) to CUR and G of the F370. F370 ← Inside Outside → ＋ External equipment － Load resistance ： 350Ω or more - Resolution The D/A converter has a resolution of 1/10000 to -10 - 10V (4 - 20mA).

  • Page 108: D/A Output Mode

    13.D/A CONVERTER(OPTION) 13-2. D/A Output Mode In synchronization with the indicated value / Fixed at 0V / Fixed at 10V / Fixed at 4mA / Fixed at 20mA In synchronization with Outputs in synchronization the indicated value with the indicated value. Fixed at 0V : The voltage output is fixed at zero output (0V).
  • Page 109 13.D/A CONVERTER(OPTION) How to output adjust Adjust the output with the dummy trimmer that appears on the adjustment screen after selecting each fixed output in the D/A output mode setting and pressing the [OK] key. While monitoring the output value, finely adjust the output with the dummy trimmer UP/ DOWN keys, and press the [OK] key to confirm, so that the trimmer position is entered.

  • Page 110: 14．Dc Power Source

    Connect the positive (+) side of the power source to the red screw side of the terminal block on the back of the F370, and its negative (-) side to the black screw side. Input voltage range (voltage between terminals of the F370) 12 - 24V DC ( ±...
  • Page 111 Although the F370 will not break down immediately even if the above messages are displayed, ADC+OVER or ADC-OVER indicates that an excessive voltage may be applied to the input circuit of the F370. It is therefore required to remove the cause immediately.

  • Page 112: 16．Self-Check And Initialization

    16.SELF-CHECK AND INITIALIZATION 16. SELF-CHECK AND INITIALIZATION 16-1. Self-Check The self-check function includes a memory check to check the memory automatically for detecting problems, a visual check to check the display visually, a touch panel key input check and an external I/O check. Self-Check DSP 16-1-1.

  • Page 113: Self-Check Key

    16.SELF-CHECK AND INITIALIZATION Self-Check KEY 16-1-3. The touch panel keys are checked. Black-bordered pseudo keys appear on the blue screen. These keys should change to white when pressed. When all keys are pressed, the original screen is restored. If the color does not change with no reaction due to a problem, it is NG.

  • Page 114: Initialization (All Setting Value Clearances)

    16.SELF-CHECK AND INITIALIZATION 16-2. Initialization (All setting value clearances) The contents of the memory are rewritten to factory defaults. In this operation, calibration values (zero calibration and span calibration) do not change but all other parameters are rewritten to factory defaults. See the section on SETTING ITEM CHART page 113 for factory defaults.

  • Page 115: 17．About Japanese/English Display Selection

    17.ABOUT JAPANESE/ENGLISH DISPLAY SELECTION 17. ABOUT JAPANESE/ENGLISH DISPLAY SELECTION The display language of the F370 is selectable between Japanese and English. JPN: Japanese ENG: English How to set Setting call → Page 2 System →...

  • Page 116: 18．Block Diagram

    18.BLOCK DIAGRAM 18. BLOCK DIAGRAM Zero Gain adjustment adjustment Low-pass ＋ SIG × 100 Fillter － SIG Conversion ＋ EXC Excitation Voltage － EXC Referrence Voltage FRAME Watch 32bit Flash ROM 128K Serial Port 8Kbyte NOV.RAM Port Port 4096bit Seria Port Port RS485...

  • Page 117: 19．Dimensions

    19.DIMENSIONS 19. DIMENSIONS Unit ： mm [ Front ] [ Side ] Panel cut out dimensions [ Rear ]...

  • Page 118: 20．Installation In A Panel

    20.INSTALLATION IN A PANEL 20. INSTALLATION IN A PANEL Follow the steps below to install the F370 in a panel. 1) Remove both side rails. 2) Make a hole in the panel in accordance with the panel cutout size. ＋ 0.8 92mm －...

  • Page 119: 21．Specifications

    21.SPECIFICATIONS 21. SPECIFICATIONS 21-1. Analog Section Sensor excitation 10V, 5V, 2.5V DC (digital adjustment) Output current: Within 120mA 4-wire (Up to four 350Ωload cells can be connected.) Signal input range -3.0 - +3.0mV/V Performed by digital computation Zero and gain adjustment Accuracy Non-linearity ：...

  • Page 120: Options

    21.SPECIFICATIONS Comparison functions External output HI-HI limit LO-LO limit HI limit LO limit Four calibration values can be stored in memory and Calibration value selection switched. 21-3. Options BCD data output Open-collector output Output rate Can be selected from 1 time/sec., 10 times/sec., 100 times/sec. and 1000 times/sec.

  • Page 121: External Input And Output

    21.SPECIFICATIONS 21-4. External Input and Output Output Output common - COM1 HI-LO limit comparison output (open-collector outputs) - HH - HI - GO - LO - LL Hold end output - H/E Serial data output SI/F start/stop system 600bps Input Input common - COM2 Parameter selection input...

  • Page 122: General

    21.SPECIFICATIONS 21-5. General - AC spec: 100V to 240V AC (+10% -15%) Required power source [free power source 50/60Hz] - DC spec: 12V to 24V DC ( ± 15%) (Depending on the request at the time of order) Power consumption - AC spec: 12W (28VA) max.

  • Page 123: Accessories

    21.SPECIFICATIONS 21-6. Accessories ・Operation Manual - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1 ・Acceptance proof - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1 ・The sticking-by-pressure terminal for external I/O terminal stand - - - 22 (TMEV1.25-3S)

  • Page 124: 22．Setting Item Chart

    22.SETTING ITEM CHART 22. SETTING ITEM CHART Setting of OPERATION　 　　　　　　　　　　　　　　　　　 N：NOVRAM　S：SRAM page Item Default Calibration Set Value LOCK LOCK Digital Filter ◎ ○ Analog Filter 300Hz ◎ ○ Display Rate 10Times ◎ ○ １ 1.5Sec Stability（Time） ◎ ○ 05CNT Stability（Cnt）...
  • Page 125 22.SETTING ITEM CHART Setting of HOLD MODE（CH00 ～ CH15） page Item Default Calibration Set Value LOCK LOCK Hold Function Tracking ◎ ○ Hold Detect Time 1.000Sec ◎ ○ Auto Start Level 00100* ◎ １ ○ Minimum Count ◎ ○ Valley Detect Level 1.0Times ◎...
  • Page 126 22.SETTING ITEM CHART Setting of Calibration page Item Default Calibration Set Value LOCK LOCK Zero Calibration ◎ ○ Actual Load Cal 10000* ○ ◎ Egv.Input Cal 3.000 ◎ ○ １ Cal. Select CAL.0 ◎ ○ Increment ◎ ○ Unit ◎ ○...
  • Page 127 22.SETTING ITEM CHART Setting of Option In case of used Output Mode page Item Default Calibration Set Value LOCK LOCK Output Mode Input Value ◎ ○ Voltage Zero Output 00000 ◎ ○ Voltage Full Scale 10000 ◎ ○ １ Current Zero Output 00000 ◎...

  • Page 128: 23．Conformity To Ec Directives

    11, EN61000-3-2, EN61000-3-3 When installing, attention should be given to the following. 1. Since the F370 is defined as an open type (built-in equipment), be sure to install the F370 and fix to a panel or the like for use.
  • Page 129 23.CONFORMITY TO EC DIRECTIVES Connection of Lightning serge protect The F370 main body conforms to EMC directive EN61000-4-5 (lightning surge immunity) in combination with the lightning surge protect. F370 Lightning surge protect (EU outlet shape) “MAINTRAB MNT-ID” lightening surge protector...
  • Page 130 - The F370 main body conforms to EMC directive EN61000-4-5 (lightning surge immunity) in combination with the lightning surge protect. - The F370 does not conform to EC directives with the CC-Link option or Device Net option, and on a DC power source.
  • Page 131 Unipulse Corporation 9-11 Nihonbashi Hisamatsucho, Chuo-ku, Tokyo 103-0005 Tel. +81-3-3639-6120 Fax: +81-3-3639-6130...
