Ecotron - Incubation Shaker
Operation
Page 50 of 90
Screw sizes
ATTENTION
If screws that are too long or too short are used to affix the hold-
ers, the holders cannot be mounted properly on the table. Not
properly mounted holders can become loose during operation
and therefore lead to property damage.
– If you have to replace lost fastening screws, you must use
screws that comply with the specification below.
Flask size
25 – 50 mL Flat head screw with Phil-
lips head M4 x 6 A4
Flat head screw with Phil-
100 – 5000 mL
lips head M4 x 8 A4
Flask size
Flat head screw with Phil-
100 – 500 mL
lips head M4 x 6 A4
Size
Ø 8 – 30 mm Oval head screw with Phil-
lips head M4 x 6 A2
Boxes for microtiter plates
Screw
Oval head screw with Phillips head
M4 x 12 A2
Steel clamps
Screw Flat gasket
Plastic clamps
Screw Flat gasket
Test tube holders
Screw Flat gasket
Flat gasket
D = 3.2 x 12 x 0.5
D = 3.2 x 12 x 0.5
D = 3.2 x 12 x 0.5
D = 3.2 x 12 x 0.5
D = 3.2 x 12 x 0.5
