7.3 Overview of Display and Operating Elements

10 8
9
1 Main switch/emergency switch
Temperature control On/Off button
2
Raise temperature button
3
4 Lower temperature button
5 View box for "Temperature" parameter (actual
values, setpoints, alarm and error messages)
Page 54 of 90
All equipment functions can be controlled directly via the operating
panel on the front of the equipment.
The operating panel comprises the following elements:
1
7
6
6
7
8
9
10 Shaker drive control On/Off button
INFORMATION
In addition to normal switching on and off, the main switch also
works as an emergency switch, if the equipment has to be
switched off in an emergency.
In case of an emergency shut down via the main switch, all pa-
rameter setpoints are stored and the equipment restarts immedi-
ately when it is switched back on via the main switch.
When the equipment is switched off using the main switch, the
parameter setpoints are stored for approx. one month.
5
Power supply on/off function symbol
View box for "Rotation speed" parameter (ac-
tual values, setpoints, alarm and error mes-
sages)
Increase rotation speed button
Decrease rotation speed button
4 3
2
