4.1.2

Tray with Pin Holders

03 May 2018
Maximum rotation speeds with «Sticky Stuff»
To ensure that the flasks do not detach from the adhesive matting,
the maximum permissible speed is limited when using adhesive
matting.
INFORMATION
The following guidelines only apply to undamaged, completely
dry adhesive matting free of grease. If old or dirty adhesive mat-
ting is used, there is a risk that flasks detach even at lower
speeds.
Flask
Unit at the bottom
(stacked or individual
25 x 300 ml
16 x 500 ml
9 x 1000 ml
4 x 2000 ml
2 x 5000 ml
For applications in which large numbers of microtitre or deep well
plates need to be incubated, various trays with pin holders are
available. These enable loading with several layers of microtitre
and deep well plates.
The plates can be stacked. This allows you to simultaneously incu-
bate up to 24 deep well plates and up to 36 microtitre plates on
one E tray.
The trays are designed for plates with the dimensions 85.1 x 127
mm.
To ensure the cultures receive the optimum oxygen supply, spac-
ers can be placed between stacked plates. These are available in
two variants:
Ecotron - Incubation Shaker
Accessories
Maximum permissible speed
Unit at the top
unit)
200 min
1
200 min 1
250 min
1
200 min
1
200 min 1
200 min
1
200 min 1
200 min
1
200 min
1
200 min 1
Page 31 of 90
