SBC86840 Series All-In-One Mini ITX Board User's Manual

2.3.1

These jumpers select the COM1 port's communication mode to

operate RS-232 or RS-422/485.

Downloaded from StockCheck.com

COM1 Mode Select Jumper: JP4, JP5, JP6

Description Function

COM1 Mode

RS-232

Select

(Default)

RS-422

RS-485

Jumper Setting

JP6

JP5

JP6

JP5

JP62

JP5

Jumpers and Connectors

JP4
