3. Product Overview
3.4.11. Ethernet Connector
The extender provides standard RJ45 connectors for
LAN port. Always use high quality Ethernet cable for
connecting transmitters and receivers.
Wiring LAN Cables
Lightware recommends the termination of LAN cables on the basis of
TIA/EIA T 568 A or TIA/EIA T 568 B standards.
8
1
Top
Bottom
Pin TIA/EIA T568 A Color and name TIA/EIA T568 B Color and name
1 white/green stripe
2 green solid
3 white/orange stripe
4 blue solid
5 white/blue stripe
6 orange solid
7 white/brown stripe
8 brown solid
Pin assignments of RJ45 connector types
3.4.12. USB Mini Connector
The extenders provide standard USB mini B-type connector for
software control and USB KVM purposes.
You can find more information about USB KVM function in the
KVM Function section.
3.4.13. USB Connector for KVM
HDMI-3D-OPT-RX150RA receiver provides USB 2.0
connectors for KVM function supporting purpose. The
unit has 2x USB 2.0 A-type connectors.
You can find more information about USB KVM function in the
KVM Function section.
3.4.14. GPIO - General Purpose Input/Output Ports
SW4-OPT-TX240RAK
8 1
8-pole Phoenix connector with seven GPIO pins,
which operates at TTL digital signal levels and can be set to high or
low level (Push-Pull). The direction of the pins can be input or output
(adjustable). Voltage ranges for GPIO inputs are the following:
Logical low level
1
Logical high level
8
INFO: The maximum total current for the seven GPIO pins is 180 mA.
Side
Pin nr.
white/orange stripe
1
orange solid
2
white/green stripe
3
blue solid
4
white/blue stripe
5
green solid
6
white/brown stripe
7
brown solid
Compatible plug type
Phoenix® Combicon series (3.5mm pitch 8-pole), type: MC 1.5/8-ST-3.5.
You can find more information about GPIO interface in the
USB
Interface
USB
HDMI-3D-OPT series – User's Manual

transmitter

contains a
Input voltage [V] Max. current [mA]
0 - 0,8 30
2 - 5 18
Level and
direction
1 2 3 4 5 6
Ground
GPIO connector and plug pin assignments
section.
3.5. Optical Extender Concept
3.5.1. Transmitter
HDMI-3D-OPT-TX200 series transmitters have a multimode single
fiber output interface which is able to transmit different type of signals
at the same time. The transmitter accepts digital video (DP, HDMI,
and DVI-D) and analog audio sources (Jack and 5-pole Phoenix). The
device can be controlled over LAN, RS-232 (3-pole Phoenix), and USB
interfaces. The transmitter is able control third-party devices using the
built-in GPIO ports. The transmitter also has USB KVM function.
Interfaces of HDMI-3D-OPT-TX210A
INPUT
HDMI
HDCP
Analog audio
7
USB
+ Local HDMI output
+ Local USB
+ Local RS-232
Interfaces of HDMI-3D-OPT-TX210RAK
INPUT
HDMI
Analog audio
HDCP
RS-232
USB
USB
+ Local HDMI output
+ Local USB
+ Local RS-232
GPIO
Interfaces of SW4-OPT-TX240RAK
INPUT
DP / HDMI / DVI-D
Analog audio
:
:
HDCP VIDEO
RS-232
USB
1 DP IN
USB
+ Local HDMI output
+ Local USB
+ Ethernet
+ GPIO
15
OUTPUT
HDMI
OPT
VIDEO AUDIO AUDIO1 AUDIO2
Analog audio
RST AUDIO SHOW
1 HDMI IN 2 AUDIO1 IN SELECT ME
OUTPUT
HDMI
Analog audio
OPT
VIDEO AUDIO AUDIO1 AUDIO2
RS-232
RST AUDIO SHOW
1 HDMI IN 2 AUDIO1 IN SELECT ME
USB
OUTPUT
HDMI / DVI-D
Analog audio
OPT
AUDIO VIDEO AUDIO VIDEO AUDIO VIDEO AUDIO1 Autoselect AUDIO2
RS-232
AUDIO RST
VIDEO AUDIO SHOW
2 HDMI1 IN 3 HDMI2 IN 4 DVI-D IN 5 AUDIO1 IN SELECT SELECT ME
USB
