4. Operation
4.4.3. FIBER LINK LED
SC MM
6
LASER APERTURE AUDIO2 IN LIVE
LASER ACTIVE
OUTPUT
FIBER LINK
RS-232
L R HDMI OUT ETHERNET
ON: Fiber link is established.
OFF: No fiber link between the transmitter and the
receiver.
4.4.4. RS-232 LED
SC MM
LASER APERTURE 6 AUDIO2 IN LIVE
OUTPUT LASER ACTIVE
FIBER LINK
RS-232
L R HDMI OUT ETHERNET
ON: RS-232 ports (local and link) are in
Mode.
BLINKING: Command Injection Mode
case of SW4-OPT-TX240RAK model)
OFF: RS-232 ports (local and link) are in
through Mode.
INFO: Only HDMI-3D-OPT-TX210RAK and SW4-OPT-TX240RAK
models has RS-232 LED.
4.5. Front Panel LEDs - Receiver
4.5.1. POWER LED
USB
FUNC.
CONT.
HDCP HOTPLUG
HDMI EMULATE
POWER
SIGNAL USB LINK
LASER FIBER LINK
ON: The receiver is powered.
4.5.2. Status LEDs
USB
FUNC.
CONT.
HDCP HOTPLUG
HDMI EMULATE
POWER SIGNAL
USB LINK
LASER FIBER LINK
HDCP
ON: Video input signal is encrypted with HDCP.
OFF: Video input signal is not encrypted with HDCP.
HDMI
ON:
PIN: 2.35mm
GPIO RS-232
BLINKING:
1 2 3 4 5 6 7 TX RX 5V DC 1A
OFF:
SIGNAL
ON:
PIN: 2.35mm
GPIO RS-232 LASER
1 2 3 4 5 6 7 TX RX 5V DC 1A
ON:
Control
HOTPLUG
is active. (only in
ON:
Pass-
EMULATE
ON:
OFF:
USB LINK
ON:
RS-232
FIBER LINK
ON:
RS-232
HDMI-3D-OPT series – User's Manual
The input and output signal type is HDMI.
The input signal type is HDMI but the output
signal is DVI.
The input signal type is DVI.
A valid video clock signal is present on the fiber
input port of the receiver.
The laser signal of a connected transmitter is
detected on the fiber input port.
A powered sink device is connected to the HDMI
OUT port and sends hotplug signal.
Composite port is active in the USB KVM
crosspoint.
No port is active or transparens port is active in
the USB KVM crosspoint.
USB KVM signal is detected on the fiber input
port.
A powered transmitter is connected to the
receiver and they can communicate over the fiber
optical cable.
4.6. Special Functions - Receiver
4.6.1. Reset to Factory Default Settings
USB
FUNC.
CONT.
HDCP HOTPLUG
HDMI EMULATE
POWER
SIGNAL USB LINK
LASER FIBER LINK
To restore factory default values, do the following steps:
Step 1. Make sure the device is powered on and operational.
Step 2. Press and keep pressed the Show Me button for 10 seconds.
After 5 seconds front panel LEDs start blinking but keep on
pressing the button.
Step 3. After 10 seconds the LEDs start blinking faster; release the
button and press it 3 times again quickly (within 3 seconds).
Step 4. The LEDs get dark, the device restores the factory default
settings and reboots.
Factory default settings are listed in the
section.
4.6.2. Entering Firmware Upgrade Mode
USB
FUNC.
CONT.
HDCP HOTPLUG
HDMI EMULATE
POWER
SIGNAL USB LINK
LASER FIBER LINK
It may happen that the firmware upgrade process is not successful
and the device cannot be switched to bootload mode automatically.
In this case, the device can be forced into firmware upgrade mode as
follows:
Step 1. Make sure the receiver is powered off.
Step 2. Press and keep pressed the Function button.
Step 3. Power on the receiver. If the device is switched to bootload
mode the Status LEDs are blinking quickly (less than 500 ms
duty cycle).
The procedure of firmware upgrade can be found in the
Upgrade chapter.
25
RS-232
Factory Default Settings
RS-232
Firmware
