To update the communicator with a new firmware version, complete the following steps at the protected
premise:
399 Programming Cable
1. Connect a DMP 399 Cable from the PROG Header to the serial port of your PC operating Remote Link and
containing the communicator RU file.
2. Start Remote Link and create or open the account that matches the communicator to be updated.
3. Set the Connection Information Type to Direct with a baud rate of 38400 and choose the appropriate
COM port.
4. Select Panel>Remote Update, then select the correct RU file for the communicator.
5. Press and hold the LOAD button, then press and release the RESET button.
6. Release the LOAD button and click <Update> in Remote Link.
7. After the firmware update is completed, remove the 399 cable and press the RESET button to resume
normal operation.
Model 400 USB Flash Module
1. Press and hold the LOAD switch. While holding the LOAD switch, press and release the RESET switch
2. Release the LOAD switch.
3. Connect the USB flash drive containing the .RU file to the Model 400 and connect the assembly to the
CellCom-LTE-V PROG header. The LED on the Model 400 will flash then display steady green.
4. Press and release the LOAD button on the Model 400 to initiate the firmware update. The LED on
the Model 400 will flash slowly. If the LED displays fast flashes it means the firmware update was
unsuccessful.
5. The update will take approximately 4.5 minutes and when complete the LED on the Model 400 will
display steady green.
6. Press and release the RESET switch then remove the Model 400 assembly.
1.6

Backlit Logo

The backlit logo indicates the Power and Armed status of the communicator. Depending on the operation, the
LED displays in Red or Green as listed in the Table 1. The LED indicates the armed state and status of the system
primary power.
Color and Activity
Green Steady
No Light
Red Steady
CellCom -LTE-V Series Installation and Programming Guide
Operation
Communicator Disarmed, Primary Power OK
No Power
Communicator Armed, Primary Power OK
Table 1: LED Status
