REMOTE ARMING AND DISARMING

4.1

Virtual Keypad App and VirtualKeypad.com

Using a Smartphone with the DMP Virtual Keypad App or using a computer with VirtualKeypad.com, you can
connect to the CellCom-LTE-V Series Communicator to arm Areas, turn Outputs on and off, and add, edit or
remove Users. When using the CellComZ-LTE-V, you can control Z-Wave devices, Favorites and Rooms. See Figure
10.
Figure 10: Virtual Keypad Application can be used to access the CellCom-LTE-V Communicator.
4.2

Using Outputs to Arm and Disarm

A burglary control panel zone may be programmed as an arming zone and connected to a CellCom-LTE-V output
O1 or O2. See Figure 11. Program the output number in Armed Output or Remote Arming Output in Output
Options when programming the communicator. See Armed Output or Remote Arming Output. The communicator
output connections can be used with any of the applications listed in Applications Section.
Control Panel
Digital Monitoring Products
10
Remote Arming and Disarming
B
Use 18-22 AWG for
12VDC Aux. Output
Power Supply connection
+
-
Zone 1
GND
Control Panel EOL resistor
Zone 2
Figure 11: Burglary Control Panel Zones Connected to the CellCom-LTE-V
Outputs to Arm and Disarm the Burglary Control Panel
MODEL CellCom-LTE-V
R
+12 G Z1 Z2 Z3
CellCom- LTE-V Series Installation and Programming Guide
G Z4+ Z4- O1 O2 T R
