MNT
13.8
NEXT ZN? NO YES
13.9

ALARM ACTION . . .

13.10

DISARMED OPEN

13.11
MSG: ALARM
A T L
13.12
OUTPUT NO:
13.13
ACTION:
CellCom -LTE-V Series Installation and Programming Guide
DIS (Disarm): A short will disarm the area. When restored to normal, no action occurs.
When the zone is opened from a normal (disarmed) state, a trouble is reported.
STEP: A short will arm the areas. A normal condition will cause no action. An open
condition will disarm the areas. When using an arming/disarming keyswitch, locate the
keyswitch within the protected area.
MNT (Maintain): When the zone is shorted, the programmed area is armed. When
restored to normal, the programmed area is disarmed and any alarm bells are silenced.
When the zone is opened from a normal (disarmed) state, a trouble is reported. If
opened from a shorted (armed) state, an alarm is reported and the zone is disabled until
you disarm the area from either the Virtual Keypad App, VirtualKeypad.com or Remote
Link.

Next Zone

When YES is selected, the programming for the zone terminates and the display returns
to ZONE NO: - allowing you to enter a new zone number. Select NO to make changes to
the Alarm Action for a zone.
Alarm Action
The Alarm Action section allows you to change or confirm the default alarm
characteristics of a zone type. If you selected the non-24-hour zone type Blank, Night,
Day, Exit, Auxiliary 1, or Auxiliary 2, the Alarm Action Programming begins with Disarmed
Open. If you selected the 24-hour zone type Panic, Emergency, or Supervisory, the Alarm
Action programming begins with Armed Open.
Disarmed Open
Defines the action taken by the communicator when the zone is opened while the area is
disarmed. There are three actions to define:

• Message to Transmit

• Output/Favorite Number

• Output Action

You must also make these selections for the Disarmed Short, Armed Open, and Armed
Short zone conditions.
Message To Transmit
You can send two report types to the receiver: Alarm and Trouble. These are represented
by the characters A and T. Press any select key or area to display the zone report
options.
- ALARM: Selecting A allows an alarm report to be sent to the receiver. The zone name
appears in the communicator's alarmed zones status lists.
TROUBLE: Selecting T allows a trouble report to be sent to the receiver and the zone
name to appear in the communicator's alarmed zones status lists.
LOCAL: When you select L, an alarm report is NOT sent to the receiver. The zone name
appears in the communicator's alarmed zones status lists.
– (dash): When you select – , reports are NOT sent to the receiver. There is no display
in the communicator's alarmed zones status list. Only the programmed Output Number
activates.

Output Number

0
You can specify any of the outputs/Favorites on the communicator to be activated by
a zone condition. The output/Favorite can be activated regardless of the report to
transmit or whether or not the zone is programmed as local. An output activated by a
non-24-hour armed zone is turned off when the zone's area is disarmed by a user. To
enter an Output Number, press any Select key followed by the output number 1 or 2.
Output Action
Entering an Output Number displays this option that allows you to assign an output
action to the output. A description of the available output actions follows:
ZONE INFORMATION
