APPLICA TION NOTE
CellComSLCF Cellular
Communicator Dialer Capture
Introduction ............................................. 1
Wiring Diagrams ..................................... 2
Ademco Vista 128FBP ........................... 2
Ademco Vista 128FBPT ......................... 3
Firelite MS-9200UDLS ........................... 6
First Alert FA1600C ............................... 7
Silent Knight 5808 ................................ 8

Basic Programming for CellComSLCF CID Dialer Capture Communication

This section provides the basic programming required for the CellComSLCF. Please see the CellComSL Series
Installation and Programming Guide (LT-1339) for complete information.
Communication:
Account No:
1 -65535
Test Time:
Use entries between 12:00 to 11:59 and then choose AM or PM.
Cell TST DAYS:
1
CHECKIN:
58 minutes for NFPA 72 2013 & UL 864 10th edition
FAIL TIME:
60 minutes for NFPA 72 2013 & UL 864 10th edition
RECEIVER 1 PROG:
ALARM:
YES
SPV/TRBL:
YES
TEST RPT:
YES
FIRST IP ADDR:
XXX.XXX.XXX.XXX
FIRST IP PORT:
Default is 2001
SYSTEM OPTIONS:
TIME CHG:
YES
HRS FROM GMT:
# Default is 6 for CST
OUTPUT OPTIONS:
COM FAIL OUT:
Either 1 or 2. The default is 0 (zero), which disables this output.
Note: This output turns on if a commnicator fails to communicate with its receiver.

Introduction

This Application Note is designed to quide technicians through
the process of installing the CellComSLCF with the Fire
Panels shown below. The information provided illustrates the
connection and programming of Fire Panels for CID Dialer
Capture using the CellComSLCF Cellular Communicator.
• Ademco Vista 128FBP
• Ademco Vista 128FBPT
• Bosch FPD-7024 Fire Control Panel
• Firelite MS-5UD
• Firelite MS-9200UDLS
• First Alert FA 1600C
• Silent Knight 5808

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CellComSLCF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DMP Electronics CellComSLCF

Summary of Contents for DMP Electronics CellComSLCF

  • Page 1: Table Of Contents

    Configure a Single Path Alarm Connection .. 9 • Silent Knight 5808 Basic Programming for CellComSLCF CID Dialer Capture Communication This section provides the basic programming required for the CellComSLCF. Please see the CellComSL Series Installation and Programming Guide (LT-1339) for complete information. Communication:...

  • Page 2: Wiring Diagrams

    1. Connect the 12VDC on the CellComSLCF to terminals 11 and 12 on the host panel. 2. Connect the phone line from TIP and RING on the CellComSLCF to the Main Phone Jack on the host panel. 3. Cut the blue jumper on the host panel or disable the TLM.

  • Page 3: Ademco Vista 128Fbpt

    1. Connect the 12VDC on the CellComSLCF to terminals 11 and 12 on the host panel. 2. Connect the phone line from TIP and RING on the CellComSLCF to the Main Phone Jack on the host panel. 3. Check that the CellComSLCF is communicating with the host panel. If it is not, cut the blue jumper on the host panel or disable the TLM.

  • Page 4: Bosch Fpd-7024 Fire Control Panel

    20 feet. Connection Instructions: 1. Connect the 12VDC on the CellComSLCF to the R and B connections on the Option Bus on the panel. 2. Connect the CellComSLCF Tip connection to the T1 and T2 connections on the host panel.
  • Page 5 JP30 1. Connect the 24VDC on CellComSLCF to the 24V Auxillary Power header on the panel. 2. Connect the phone line from TIP and RING on the CellComSLCF to J8 on the host panel. 3. Normal Central Station programming. Note: This only applies to CellCom SLCF Rev 4 Lev E.

  • Page 6: Firelite Ms-9200Udls

    Connection Instructions: 1. Connect the 24VDC on the CellComSLCF to the TB2 header on the host panel. 2. Connect the phone line from TIP and RING on the CellComSLCF to PH15 on host panel. 3. Normal Central Station programming. Firelite...

  • Page 7: First Alert Fa1600C

    20 feet. Connection Instructions: First Alert 1. Connect the 12VDC on the CellComSLCF to terminals 11 and 12 on the host panel. FA 1600C 2. Connect the phone line from TIP and RING on the CellComSLCF to the Main Phone Jack on the host panel.

  • Page 8: Silent Knight 5808

    TELCO 2 PHONE 2 Connection Instructions: 1. Connect the 24VDC on the CellComSLCF to the + and - terminals on the host panel. 2. Connect the phone line from TIP and RING on the CellComSLCF to TIP and RING on host panel.

  • Page 9: Configure A Single Path Alarm Connection

    If this option is not applicable due to panel limitations, both TIP and RING connections may be connected from the panel into the CellComSLCF. The CellComSLCF has the capability of monitoring and providing a dial tone to both telco connections.
