5.6

Entering Letters and Special Characters

Some options during programming require you to enter Letters and Special Characters. Use the Number Pad
directions below to enter letters and special characters on a number pad or use the Standard Keyboard directions
to enter letters and special characters on a standard keyboard.
Number Pad
1. Choose a character from Table 5.
2. Identify the Number the character correlates with and press that number on the number pad.
3. Identify the Select Key or Area for that character and press that select key or area on the keypad. To
access the lowercase letter, press that select key or area again.
4. When the desired character displays on the keypad, return to Step 1 to enter another character or press
CMD if finished.
Standard Keyboard
• Press ABC to access uppercase letters.
• Press abc to access lowercase letters.
• Press !@# to access symbols and special characters.
• Press 123 to access the number pad.
5.9

Keypad Displays Current Programming

Each programming option displayed at the keypad shows the currently selected option in the communicator
memory. These options are either shown as a number, a blank, or a NO or YES. To change a number or blank
to a new number, press any top row select key or area. The current option is replaced with a dash. Press the
number(s) on the keypad you want to enter as the new number for that option. It is not necessary to enter
numbers with leading zeros. The communicator automatically right justifies the number when you press CMD.
To change a programming option that requires a NO or YES response, press the select key or area for the
response not selected.
For example, if the current option is selected as YES and you want to change it to NO, press the third top row
select key on LCD keypads. On graphic touchscreen keypads, touch select area 3. The display changes to NO.
Press CMD to display the next option.
CellCom -LTE-V Series Installation and Programming Guide
PROGRAMMING INTRODUCTION
Number Select Key 1
1 A
2 D
3 G
4 J
5 M
6 P
7 S
8 V
9 Y
0 -
Table 5: Entering Letters and Special Characters in the Number Pad
Select Key 2 Select Key 3 Select Key 4
B C
E F
H I
K L
N O
Q R
T U
W X
Z space
. *
(
)
!
?
/
&
@
,
_
#
