Z-WAVE SETUP
16.3

RENAME Z-Wave Devices

1. Access the User Menu.
2. Press CMD until ZWAVE SETUP? displays.
3. Press any Select key. The keypad displays ADD LIST REMOVE.
4. Select LIST to display DEVICE LIST and the first Z-Wave device stored. Press the CMD key to advance through
the list of Z-Wave devices.
5. Press any Select key to display DEVICE RENAME STATUS.
6. Select RENAME and enter up to 16 characters for a new device name. See Entering Names in Appendix D.
7. Press CMD to save the new Z-Wave device name and return to the DEVICE LIST.
16.4

STATUS of Z-Wave Devices

1. Access the User Menu.
2. Press CMD until ZWAVE SETUP? displays.
3. Press any Select key. The keypad displays ADD LIST REMOVE.
4. Select LIST to display DEVICE LIST and the first Z-Wave device stored. Press the CMD key to advance through
the list of Z-Wave devices.
5. Press any Select key to display DEVICE RENAME STATUS.
6. Select STATUS to confirm radio communication with the Z-Wave device.
7. The device name and OKAY displays when the device stored in the system communicates.
8. Press the CMD key to return to the device list and display the next device in the list.
9. If the device stored in the system does not communicate, the device name and FAILED displays. Press the
CMD key and REMOVE FAILED DEVICE displays.
10. Select YES to remove the failed device from the system memory. Select NO to leave the device in the system
memory and to return to the device list.
11. When the device has been removed, the device name and REMOVED is displayed and the system no longer
tries to communicate with the Z-Wave device.
16.5

Remove Z-Wave Devices (REMOVE)

Each Z-Wave device added to your system remains in your system unless it is removed. This option allows you to
remove Z-Wave devices from your system.
1. Access the User Menu.
2. Press CMD until ZWAVE SETUP? displays.
3. Press any Select key. The keypad displays ADD LIST REMOVE.
4. Select REMOVE. PROCESSING may briefly display. When PRESS BUTTON ON DEVICE TO REMOVE displays
press the program button on the Z-Wave device, the device name and REMOVED is displayed to indicate
the Z-Wave device has been removed.
16.6

Favorites (FAV)

Z-Wave devices can be grouped together to create a Favorite. This option allows you to program up to 20
Favorites in your system and then ADD, EDIT OR REMOVE up to 25 Z-Wave devices in a Favorite. When activated
from the FAVORITE user menu, a command is sent to its Z-Wave Devices. A Favorite can only be activated, or
turned on. A separate Favorite must be created to change the conditions set by the first Favorite. For example, a
Favorite called "Movie Night" could lock the exterior doors, close the garage door, adjust the temperature, and
dim the lights in the family room to the desired level. Another Favorite called "Wakeup" could then turn on the
lights, adjust the temperature, unlock the exterior doors, and raise the garage doors.
