Your system may include a DMP Z-Wave controller. The Z-Wave controller allows short range radio control of Z-Wave
devices that you or your installation company may provide such as lighting control modules, thermostat controls, doors,
and garage doors. Z-Wave Setup allows you to program the system to control the Z-Wave devices. Users can control Z-Wave
devices from a smartphone, tablet, or desktop computer using the Virtual Keypad App or VirtualKeypad.com. The available
setup options are Add, List, Remove, Favorites, Transfer and Optimize.
• Select ADD to add a Z-Wave device to your system.
• Select LIST to display a list of Z-Wave devices already added and stored in your system.
• Select REMOVE to completely remove a Z-Wave device from your system.
• Select FAV to Add, Edit or Remove a Favorite.
• Select XFER to transfer Z-Wave device information from another manufacturer's portable Z-Wave controller to your
system.
• Select OPT to update communication with all Z-Wave devices programmed on your system. OPT can be used to re-
establish communication after a Z-Wave device has been moved to a different location.
Note: Only Master User Code Level can access Z-Wave Setup through the User Menu to program Z-Wave devices. For
information on adding Z-Wave devices from the Virtual Keypad App, tap Online Help from the Settings tab in the app.
16.1

Add Z-Wave Devices (ADD)

This option allows you to ADD a Z-Wave device to a system. Once added, a Z-Wave device may be assigned to a
Favorite.
1. Access the User Menu.
2. Press CMD until ZWAVE SETUP? displays.
3. Press any Select key. The keypad displays ADD LIST REMOVE.
4. Select ADD. PROCESSING may briefly display. When PRESS BUTTON ON DEVICE TO ADD displays press the
program button on the Z-Wave device. See the Z-Wave device's documentation for more information.
5. When the device information is received by the system, the keypad beeps once and displays DEVICE
FOUND.
6. Once added, the keypad displays the type of device and the default device name. Press CMD.
7. Press any top row Select key and enter up to a 16 character custom name for the device.
8. Press the CMD key to store the new name.
Note: A maximum of 140 Z-Wave devices can be added to the system. When the maximum number of devices
have been added, the keypad displays ZWAVE TABLE FULL and no additional Z-Wave devices may be added
without removing some existing devices.
16.2

List Z-Wave Devices (LIST)

This option allows you to edit the name of a Z-Wave device or confirm radio communication with the Z-Wave
device. When LIST is selected, the first Z-Wave device stored in the system is displayed. Remaining devices can
be viewed by pressing the CMD key. Lighting control modules, are displayed first, followed by doors and then
thermostat controls.
The available LIST options are: Rename and Status.
• Select RENAME to enter up to 16 characters for a new device name.
• Select STATUS to confirm radio communication with the Z-Wave device.
