Remote Arming/Disarming for Ademco Vista Control Panels

The following steps describe how to configure the CellCom-LTE-V to arm and disarm an Ademco Vista control
panel from a schedule or remotely from the Virtual Keypad App, VirtualKeypad.com, or RemoteLink™ using the
Remote Arming Output.
1. Connect output 17 (far left pin on the 7 pin header located in the middle of the PCB) to Zone 1 (Z1) on the
CellCom-LTE-V. Connect a 1k ohm EOL resistor from Zone 1 to ground (G).
2. Connect Output 1 (O1) on the CellCom-LTE-V to Zone 3 (terminal 12) on the Vista control panel.
3. Enter programming by entering the Installer Code followed by 800. Press * and Field ? displays.
4. Program Zone 3 as an Arming Zone. Enter 56 and program the following:
a. Set to Confirm? - Enter 0.
b. Enter Zn Num. - Enter 03, press * to continue.
c. Summary Screen: Zn ZT P RC HW:RT - Press * to continue.
d. Zone Type - Enter 77, press * to continue.
e. Report Code 1st 01 2nd 00 10 - Press * to continue.
f. Hardware Type - Enter 0, press * to continue.
g. Resp Time - Enter 1, press * to continue.
h. Summary Screen: Zn ZT P RC HW:RT - Press * to continue.
i. Program Alpha - Enter 0.
j. Enter ZN Num displays, enter 00 to exit.
5. Program Output 17. Enter * or # displays. Press * and Field? displays. Enter 79 and program the following:
a. Enter Output No - Enter 17, press * to continue.
b. Output Normally Low - Enter 0, press * to continue.
c. Enter Output No displays. Enter 00 to exit.
6. Define Output 17 actions. Enter * or # displays. Press * and Field? displays. Enter 80 and program the
following:
a. Program Output 17 to turn on when armed Stay. Output Funct# - Enter 01, press * to continue.
• Summary Screen: 01 A E P Trig - Press * to continue.
• Activated by: - Enter 2, press * to continue.
• Enter Zn Type - Enter 20, press * to continue.
• Output Action - Enter 2, press * to continue.
• Enter Output No. - Enter 17, press * to continue.
• Summary Screen: 01 A E P Trig - Press * to continue.
b. Program Output 17 to turn on when armed Away. Output Funct# - Enter 02, press * to continue.
• Summary Screen: 02 A E P Trig - Press * to continue.
• Activated by: - Enter 2, press * to continue.
• Enter Zn Type - Enter 21, press * to continue.
• Output Action - Enter 2, press * to continue.
• Enter Output No. - Enter 17, press * to continue.
• Summary Screen: 02 A E P Trig - Press * to continue.
c. Program Output 17 to turn off when Disarmed. Output Funct# - Enter 03, press * to continue.
• Summary Screen: 03 A E P Trig - Press * to continue.
• Activated by: - Enter 2, press * to continue.
• Enter Zn Type - Enter 22, press * to continue.
• Output Action - Enter 0, press * to continue.
• Enter Output No. - Enter 17, press * to continue.
• Summary Screen: 03 A E P Trig - Press * to continue.
d. Output Funct# - Enter 00, press * to continue.
7. Enter * or # displays. Press * and Field? displays. Enter 99 to exit programming.
8. Programming the CellCom-LTE-V.
a. Reset the CellCom-LTE-V. Enter 6653.
b. Press CMD to Output Options. Press any select key (top row key).
c. Program Output 1 in Remote Arming Output. Press CMD to RMT ARMG OUT:. Enter 1 CMD.
d. Press CMD to Zone Information. Press any select key and Zone No. - displays.
e. Enter 1, press CMD.
f. Enter a zone name. Press CMD.
g. Program Zone 1 as an Arming Zone. Zone Type: - displays. Choose Arming Zone type AR. Press CMD.
h. Area: 1------ displays. Press CMD.
i. Style: TOGGLE displays. Choose MNT.
j. Exit Programming.
