7.1

COMMUNICATION

7.2
ACCOUNT NO:
7.3
XMIT DELAY:
7.4
COMM TYPE: CELL
7.5

TEST TIME

00:00 AM
7.6
CELL TST DAYS:
7.7
CHECKIN:
7.8

FAIL TIME:

7.9
RECEIVER 1 PROG
7.10
ALARM NO
7.11
SPV/TRBL NO
7.12
O/C USER NO
CellCom -LTE-V Series Installation and Programming Guide
Communication
Communication
The Communication section allows you to configure the communication settings for the
CellCom-LTE-V Series Universal Alarm Communicator.

Account Number

Enter the account num ber sent to the receiver (Range is 1-65535). For account numbers
of four digits or less, you do not have to enter leading zeros.

Transmission Delay

0
Enter the number of seconds (15 to 45 seconds, default is 0) the communicator waits
before sending burglary alarm reports to the receiver. Enter 0 (zero) to disable this
function.

Communication Type

The communicator uses CELL communication to DMP Model SCS-1R or SCS-VR Receivers.
Test Time
Enter the time of day the communicator should send the test report to the SCS-1R or
SCS-VR Receivers. Use entries between 12:00 to 11:59 and then choose AM or PM. To
enable daily tests from the host panel, leave the time blank and enable test reports for
receiver 1 (see 7.13) and/or for receiver 2 (see 7.22).

Test Days

1
If you entered a Test Time, you have the option to enter how often the panel test report
is sent to the receiver. (Range is 1 to 60, default is 1) Enter zero to disable the test
report.

Cell Check-In

0
Check-in reports are a method of supervising the panel for communication with the
receiver. Enter the number of minutes between check-in reports. (Range is 3-240,
default is 0). Enter 0 (zero) to disable Check-In minutes.
Note: Additional cell charges may apply if this option is used.
Fail Time
0
Fail Time allows the SCS-1R or SCS-VR receiver to miss a defined number of check-ins
before logging that the panel is missing. For example, if CELL CHECKIN is 20 minutes
and FAIL TIME is 30 minutes, the SCS-1R receiver only indicates a Panel Not Responding
after 30 minutes. The FAIL TIME must be equal to or greater than the CELL CHECKIN
minutes: If the CHECKIN is 20 minutes, the FAIL TIME must be 20 minutes or more.
(Range is 3-240, default is 0)

Receiver 1 Programming

This option allows you to set the options for the first receiver the communicator
attempts to contact when sending reports from the host panel and/or the CellCom-LTE-V
communicator. The communicator supports communication up to two receivers.

Alarm Reports

YES
YES enables Abort, Alarm, Alarm Restoral, Alarm Bell Silenced, Ambush, Exit Error, and
System Recently Armed reports to be sent to this receiver. (Default is YES)

Supervisory/Trouble Reports

YES
YES enables Supervisory, Trouble, Trouble Restoral, Force Armed, and Fault reports to be
sent to this receiver. (Default is YES)

Opening/Closing and User Reports

YES
YES enables Opening/Closing, Schedule and Code Changes, and Bypass reports by user to
be sent to this receiver. (Default is YES)
COMMUNICATION
Digital Monitoring Products
15
