OUTPUT OPTIONS

11.1
OUTPUT OPTIONS
11.2
CO OUTS: - -
11.2.1
CUTOFF TIME:
11.3
COMM FAIL OUT:
11.4
ARMED OUT:
11.5
RMT ARMG OUT:
11.6
HEAT SAVER
TEMPERATURE:
11.7
COOL SAVER
TEMPERATURE:
Digital Monitoring Products
22
Output Options
Output Options
This section allows you to program communicator output options. Switched Ground
(open collector) outputs are available using terminals O1 and O2 as the ground and your
control panel for power. Select from outputs 1 or 2.

Cutoff Outputs

This option allows you to define the operation of the two on-board outputs. For each
programming option, enter the number of the output you wish to activate or 0 (zero) for
no output. Either or both of the available outputs can be programmed here to turn off
after the time specified in Output Cutoff Time. To disable this option, press any Select
key to clear the display of output numbers and then press CMD.

Output Cutoff Time

0
If a Cutoff Output is assigned, you can enter a Cutoff Time for the output to remain
on up to 15 minutes. If the output is turned off manually, the cut off time is reset. The
Cutoff Time can be 1 - 15 minutes. Enter 0 (zero) to provide continuous output.
Note: The output is cutoff within 60 seconds of the programmed cutoff time.
The Cutoff Timer is shared by all outputs. If a second output trips, the timer is not
reset. Both outputs turn off when the original time expires.

Communication Failure Output

0
This Output/Favorite turns on when the communicator fails to communicate with the
receiver. To turn off the Communication Failure Output, disarm the communicator.
Favorites are only available on the CellComZ-LTE-V Communicator. Enter 0 (zero) to
disable this output.

Armed Output

0
This Output/Favorite turns on any time an area of the system is armed. The output turns
off when the system completely disarms. Enter 0 (zero) to disable this output.

Remote Arming Output

0
When the system is armed or disarmed remotely from the Virtual Keypad App,
VirtualKeypad.com, RemoteLink, or from a schedule, this Output turns on momentary for
.75 seconds then turns off. This Output can be used for panels that require a momentary
short to an arming zone to arm and a momentary short to disarm.

Heat Saver Temperature (CellComZ-LTE-V only)

Enter the desired temperature setting for all Z-Wave thermostats when the system
0
is armed ALL. When the system is disarmed the thermostats return to their previous
settings. The range is 55-95 degrees. Enter 0 (zero) to disable.

Cool Saver Temperature (CellComZ-LTE-V only)

Enter the desired temperature setting for all Z-Wave thermostats when the system
0
is armed ALL. When the system is disarmed the thermostats return to their previous
settings. The range is 55-95 degrees. Enter 0 (zero) to disable.
CellCom- LTE-V Series Installation and Programming Guide
