COMMUNICATION
7.13
TEST RPT NO
7.14
FIRST IP ADDR
000.000.000.000
7.15

FIRST IP PORT

2001
7.16
SECOND IP ADDR
000.000.000.000
7.17

SECOND IP PORT

2001
7.18
RECEIVER 2 PROG
7.19
ALARM NO
7.20
SPV/TRBL NO
NO
7.21 O/C USER
7.22
TEST RPT NO
7.23
FIRST IP ADDR
000.000.000.000
Digital Monitoring Products
16

Test Report

YES
Enter YES to enable the Recall Test report from the host panel and/or CellCom-LTE-V
communicator to be sent to this receiver. (Default is YES)

First IP Address

Enter the first (primary) IP address where the communicator sends cell messages. Enter
all 12 digits and leave out the periods. For example, enter IP address 192.168.0.250 as
192168000250. The periods display automatically.
First IP Port
Enter the first IP port number to be used in conjunction with the First IP Address. The IP
port identifies the port used to communicate messages to and from the communicator.
(Default IP Port setting is 2001)

Second IP Address

Enter the second IP address where the communicator sends network messages. Enter
all 12 digits and leave out the periods. For example, enter IP address 192.168.0.250 as
192168000250. The periods display automatically.
Second IP Port
Enter the second IP port number to be used in conjunction with the Second IP Address.
The IP port identifies the port used to communicate messages to and from the
communicator. (Default IP Port setting is 2001)

Receiver 2 Programming

This option allows you to set the options for the second receiver the communicator
attempts to contact when sending reports from the host panel and/or the CellCom-
LTE-V communicator. The communicator supports communication up to two receivers. If
you select YES for any of the Receiver 2 options, you must have at least one IP address
programmed in Receiver 2 programming. (Receiver 2 defaults are set to NO)

Alarm Reports

YES
YES enables Abort, Alarm, Alarm Restoral, Alarm Bell Silenced, Ambush, Exit Error, and
System Recently Armed reports to be sent to this receiver. (Default is NO)

Supervisory/Trouble Reports

YES
YES enables Supervisory, Trouble, Trouble Restoral, Force Armed, Late to Close, and
Fault reports to be sent to this receiver. (Default is NO)
YES

Opening/Closing and User Reports

YES enables Opening/Closing, Schedule and Code Changes, and Bypass reports by user to
be sent to this receiver. (Default is NO)

Test Report

YES
Enter YES to enable the Recall Test report from the host panel and/or CellCom-LTE-V
communicator to be sent to this receiver. (Default is NO)

First IP Address

Enter the first (primary) IP address where the communicator sends cell messages. Enter
all 12 digits and leave out the periods. For example, enter IP address 192.168.0.250 as
192168000250. The periods display automatically.
