APPENDIX

This section of the CellCom-LTE-V Series Universal Alarm Communicator Installation/Programming Guide provides
additional zone and system information.
17.1

False Alarm Reduction

System Recently Armed report
The System Recently Armed report (S78) is sent when a burglary zone goes into alarm within two minutes of the
system being armed.
17.2

Diagnostics Function

The communicator contains a Diagnostics function that allows you to test the integrity of the cellular
communication, cellular signal, and check Panel Settings. To use Diagnostics, reset the communicator, enter the
Diagnostics code 2313 (DIAG).
Cellular Status
This option tests the individual components of cellular communication. Entry into the CELL STATUS menu
will prompt each component of the cellular communication to be tested. The test will proceed until the first
component failure or until all components have been tested with positive results. The test screen will display
after each component and will be displayed for two seconds or until CMD has been pressed.
-XX dBm
SIGNAL:
▐▐▐▐▐▐▐
Panel Settings
Pressing a top row key allows access to the MAC Address, Serial Number, Model, and Firmware Version.
Serial Number
This number is the communicator serial number. Reference this number for communicator date-of-manufacture,
hardware version, etc. Press any top row Select key to display the Serial Number.
Model Number
This menu option displays the model number of the communicator .
Firmware Version
This menu option displays the firmware version number of the communicator and date it was released.
Digital Monitoring Products
34
Appendix
Cellular Signal Strength (CELL SIGNAL)
This option provides a way to test the cellular signal strength of the nearest tower for
the cellular carrier. Press any top row Select key to display cell signal strength. The X's
represent the numerical value of the cell signal strength in -dBm. The
signal strength 0-7.
CellCom- LTE-V Series Installation and Programming Guide
's represent the
