APPENDIX

This section provides additional zone and system information.

False Alarm Reduction

System Recently Armed report
The system recently armed report (S78) is sent when a burglary zone goes into alarm within two minutes of the
system being armed.

Diagnostics Function

The communicator contains a diagnostics function that allows you to test the integrity of the cellular communication
and cellular signal. You may also check panel settings with the diagnostics function. To use diagnostics, reset the
communicator and enter the diagnostics code 2313 (DIAG).
Communication Status
This option tests the individual components of cellular or network communication. The displayed results are shown
below.
Cellular Results
Successful Display
MODEM OPERATING
IDENTIFIED
TOWER DETECTED
REGISTERED
SIGNAL:
▐▐▐▐▐▐▐
CONTINUE? NO YES
Successful Display
CONNECTED
COMM PATH GOOD
Network Results
Successful Display
LINK OK
DHCP OK
GATEWAY FOUND
DEST FOUND
COMM PATH GOOD
‑XX dBm
SIGNAL: ▐▐▐▐▐▐▐
DualCom Programming and Installation Guide
Failure Display
NO MODEM FOUND
NO SIM CARD
NO TOWER
NOT REGISTERED
This displays the cellular signal strength of the nearest tower for the SIM card carrier.
The ▐ 's represent the signal strength 0‑7. Select YES to continue through the remaining
component tests. Select NO to stop testing and return to the COMM STATUS option.
Failure Display
CONNECT ERROR
NOT ACTIVATED
NO ACK RECEIVED
Failure Display
LINK ERROR
DHCP ERROR
NO GATEWAY
NO DESTINATION
NOT CONNECTED
NO ACK RECEIVED
Cellular Signal Strength (CELL SIGNAL)
This option provides a way to test the cellular signal strength of the nearest tower for the
cellular carrier. Press any select area to display cell signal strength. The X's represent the
numerical value of the signal strength in ‑dBm. The ▐ 's represent the signal strength 0‑7.
