4.1

DMP Virtual Keypad App / Virtual Keypad Browser

Using a Smartphone with the DMP Virtual Keypad App or using a computer with the Virtual Keypad Browser
(www.myvirtualkeypad.com), you can connect to the CellComSL Series Communicator to arm Areas, turn Outputs
on and off, and add, edit or remove Users. When using the CellComSLCZ, you can control Z-Wave devices,
Favorites and Rooms.
Figure 12: Virtual Keypad Application can be used to access the CellComSL Series Communicator.
Control Panel
12 Vdc Aux. Output
Zone 1
GND
Zone 2
Figure 13: Burglary control panel zones connected to the CellComSL Series outputs to
arm and disarm the burglary control panel.
A burglary control panel zone may be programmed as an arming zone and connected to a CellComSL output
(O1 or O2) (See Figure 13). Program the output number in Armed Output or Remote Arming Output in Output
Options of the CellComSL (See Armed Output or Remote Arming Output). The CellComSL Communicator output
connections can be used with any of the applications listed in Applications Section.
CellComSL Series Universal Communicator Installation and Programming Guide

remote armIng/dIsarmIng

Remote Arming/Disarming
B R
Use 18-22 AWG for
Power Supply connection
+
-
Control Panel EOL resistor
MODEL CellComSL
+12 G Z1 Z2 Z3 G Z4+ Z4- O1 O2 T R
Digital Monitoring Products
7
