18.4.7 Configuring the Keba Power Charging Stations
The Keba power charging station can be selected and configured accordingly from the Device Configurati-
Configuration | Device | Configuration
on section in the
Procedure:
•
Select the Keba power charging station from the drop-down menu under devices.
•
The model, address and serial number are automatically applied and cannot be modified.
•
The following configurations can be made under Charge control:
• There are different selection options for the
• Not controlled
• any control of the charging process.
• Surplus - The electric car only changes when there is enough PV power available. The So-
lar-Log™ takes the defined minimum charge level into consideration. In this case, the release
of power for the charging station corresponds to the amount of surplus.
• Surplus / minimum charge
level even when no PV power is available. When there is an energy surplus, the Solar-Log™
informs the charging station.
Always charge
•
restrictions, regardless of the production or surplus levels.
• min. Charge Current [mA]
• max. Charge Current [mA]
Off delay [Min.] (only when used with the Charge limitation „Surplus")
option defines when the charging process should be stopped after the previous surplus is no
longer available. This option prevents the charging process from being interrupted by short-
term fluctuations in the amount of available surplus. The time factor can be defined from 1 to 60.
Forced charge via Switch (X1):
•
• Activated.
• Deactivated.
•
Select the operating mode from the meter configuration menu. The Keba power charging station
can be configured as a consumption meter or a sub-consumer.
•
Enter the description under Module Fields, Power Output and Descriptions.
•
SAVE the settings .
Note about forced charging via wall switch (X1)
If a wall switch is installed and connected to X1 on the charging station, the charging station is allowed via
the Solar-Log™ to consume the defined maximum power levels without any restrictions, regardless of the
production or surplus levels.
If a wall switch has not been installed, the Solar-Log™ configuration defined for the current limiting functi-
on can be set to „always charge." This also allows for charging according to the defined maximum power
level.
- The Solar-Log™ only records the charging data without
- This ensures that the car always reaches its minimum charge
- The Solar-Log™ allows the charging station to consume power without any
- The defined minimum charging power value is taken into account.
- The defined maximum charging power value is taken into account.
menu.
Charge limitation
function in this section:
Configuring connected devices
- The switch-off delay
