18 Configuring connected devices

Configuration | Devices
From the menu
•
defined
•
detected
•
and configured.
We recommend the following procedures for new installations:
•
First define the interface to be used for the connected devices
•
Device Detection
•
Device configuration
18.1

Device definition

Configuration | Devices | Definition
The
•
Interfaces
•
CT (only Solar-Log™ Meter)
•
Large external display (advanced settings have to be activated)
•
SCB (only Solar-Log 1000 and 2000)

18.1.1 Configuring the device interface

The interface for the connected devices needs to be defined from the
| Interfaces
menu before performing a device detection.
Procedure:
•
Go to the plus symbol under "

Fig.: Interface definition via the plus symbol

, the PV plant components connected to the Solar-Log™ can be
menu is divided into the following sub-sections:
Interface assignments" .
Configuring connected devices
Configuration | Devices | Definition
