Editing Data

21 Editing Data
Configuration | Data
The
and contains the following options:
•

Initial yield

•
Data correction
•
System backup
•
Backup
•
Reset
21.1 Initial yield
This function manually imports initial yields from previous recorded daily data into the Solar-Log. This is
useful any time that a large amount of data has to be changed and would take too long with the "Data cor-
rection" function.
The Data import deletes the existing data memory completely before the daily data is imported from a
CSV file. Therefore, the data import should be carried out immediately after the startup of Solar-Log™.
The Initial yield can contain production, consumption or self-consumption values.
Note!
The data has to be in the CSV format for the import. Files in the CSV format can be created with simple
text editors or spreadsheet programs like MS Excel or Open Office Calc.
The import file must consist of individual rows of text, in which the date and daily yield value in "Wh" (not
kWh!) are separated by semicolons (CSV format).
Example:
DD.MM.YY; Production in Wh; Consumption in Wh; Self-consumption in Wh
12.12.16;136435;264371;33684
13.12.16;138219;213145;43476
etc.
Note: Here, the year value should also consist of 4 digits.
Procedure
•
Click on
•
The file manager of your OS appears.
•
Select the CSV file
•
The selected file name is displayed
•
Click on
•
The progress and status of the data import are displayed
Upload file
End current measuring
116
menu offers several functions in regard to the data recorded by the Solar-Log™
A data import can only be made if all inverters have been correctly detected and config-
ured or if a valid system configuration has been imported.
Browse .
that is to be imported
Upload .
