Smart Energy
Generation Information on Thresholds
Average values (every 5, 10 or 15 minutes) are generated to balance the fluctuations in PV production (e.g.
due to clouds) for managing appliances. The average value is aligned to the threshold set in the respective
logic control.
General information about nominal power (maximum AC output):
The nominal power (maximum AC output) is the average consumption of appliances that is controlled by
the profile. Appliances, such a laundry dryer, have a short high peak of power consumption and times in
which little power is required. Based on this, it would be problematic to calculate the current power con-
sumption for power management control. The is why the Solar-Log™ calculates the entire runtime with the
value configured for the nominal power (maximum AC output) which can be entered in the
| Devices | Configuration | Configuration
(See the Chapter "
Note!
Note!
Note!
140
Module Fields, Power Output and Descriptions
The most exact that the configured nominal power (maximum AC output) corresponds
to the actual consumption, the more accurately the control of consumption via Smart
Energy is.
The configured control rules can be simulated in the Diagnostics menu. Click on the
arrow symbol at the top under
switch directly to the Smart Energy Simulation.
(See the User Manual for more information about the Smart Energy Simulation.)
A detailed document about Smart Energy with practical examples is available from our
website:
http://www.solar-log.com/en/products-solutions/solar-logtm-smart-energy/homepage.
html for Download .
Module Fields, Power Output and Descriptions
in the
" under
Configuration | Smart Energy | Switching groups
Configuration
section.
Device Configuration .)
