Wiring for Inepro 1250D meter via S0
Article Number: 255421
Inepro 1250D
S0
Solar-Log™
PIN
1
2
3
4
Place a cable bridge between pin 3 and 4 on the Solar-Log™.
Wiring for Iskra WS0021 meter via S0
Article Number: 255346
Iskra WS0021
S0
Solar-Log™
PIN
1
2
3
4
Place a cable bridge between pin 3 and 4 on the Solar-Log™.
Wiring for Iskra WS0031 meter via S0
Article Number: 255347
Inepro 1250D
S0
Solar-Log™
PIN
1
2
3
4
Place a cable bridge between pin 3 and 4 on the Solar-Log™.
Power meter
Assignment
Pin 9 - S0+
Pin 8 - S0-
Power meter
Assignment
Pin 9 - S0-
Pin 8 - S0+
Power meter
Assignment
S0+
S0-
Connecting accessories
49
