Solar-Log 200 Installation Manual page 158

Feed-In Management
Procedure
•
Variable reactive power via the characteristic curve Q(U)
Select
•
Activate the
•
Select 2-point characteristic curve
•
Define the
check in front of inductive/under-excited.
•
SAVE the settings.
The characteristic curve displayed changes according to the values entered.
4-point characteristic curve
By selecting "4-point characteristic curve" it is possible to define a characteristic curve using four points.
Procedure:
•
variable reactive power via the characteristic curve Q(U)
Select
•
Activate the
•
Select 4-point characteristic curve
•
Define the
check in front of inductive/under-excited.
•
SAVE the settings.
The characteristic curve displayed changes according to the values entered.
Reductions
The following configuration options are available in the Reductions section.
•
Gradient limit (adjustment rate):
If the power company requires a reduction, it has to be configured in this box. (Enter the values in
seconds)
•
Max. cos(phi) inductive/under excited and max. cos(phi) capacitive/over-excited:
A maximum shift factor can be defined wit this the reduction. With this, it can be that less reactive
power is fed-in into the grid than what the characteristic curve allows in the partial load range in
order to maintain the shift factor limits.
Note!
158
interface assignments
.
characteristic curve points A and B
interface assignments
.
characteristic curve points A, B, C and D
Entering zero as the value deactivates the particular limit.
to control.
based on the boxes U/Uc, Q/SAmax and put a
to control.
based on the boxes U/Uc, Q/SAmax and put a
as the type.
as the type.
