Display - Solar-Log 200 Installation Manual

System Configuration

22.3 Display

The following options are available from the
•
Dimming at a certain time
•
Dimming when all of the inverters are offline
•
Dimming after inactivity
•
Slide show dialog
The settings refer to the touch display. The small LCD display is continuously in operation.
Dimming at a certain time
The display brightness can be limited to a certain period. If the display is touched, the screen lights up
again.
Procedure
•
Enter the
Times are to be entered in the hh:mm format
For example: 19:30 (for 7:30 p.m.)
•
SAVE the settings.
Dimming when all of the inverters are offline
When this function is active, the Solar-Log™ automatically dims when all of the inverters are offline (no
more power feed). The Solar-Log automatically resumes from the sleep the next morning and starts re-
cording again.
Dimming after inactivity
The display brightness can be dimmed by 50% and/or 100% after a certain period. If the display is touched,
the screen lights up again completely.
Procedure
•
Activate
•
Enter the
The minutes are to be entered in the mm format,
for example, 60 for 60 minutes
•
SAVE the
Slide show section
After a defined period of time, the display changes about every 15 seconds: Overview, Tachometer, Energy
Flow, Balance, Forecast, Day, Month, Year, Total, Environmental Contributions 1 - 3.
Procedure
•
Enter the
The minutes are to be entered in the mm format,
for example, 15 for 15 minutes.
•
The starting view of the Slide show can be set from the start screen.
•
SAVE the settings.
•
Alternatively, a start screen can be set for when the Slide show is deactivated.
126
Turn on at Turn off at time
and
Dimming level switch.
Period of inactivity in minutes
.
settings .
desired time in minutes.
Configuration | System | Display
on the display.
menu:
