Smart Energy Switching Groups - Solar-Log 200 Installation Manual

•
Gude:
• 1002
• 1100/1001
• 2104
• 2110
• 2301
•
Solar-Log:
• Relay (only Solar-Log 1000, 1200 and 2000)
• Smart Relay Box
• Smart Relay Station 1x 3.5kW
• Smart Relay Station 3x 3.5kW
After that, the number of devices still has to be defined; up to 10 devices are available in total. The Smart
Relay Box is the only exception here, instead of the device number box, the interface has to be selected.
•
If the definition is complete, confirm by selecting
•
Define additional switches in the same way.
•
Start the detection after defining the interfaces (see Chapter 18.4 "Device Detection").
•
Configure the switches after the detection (See Chapter 18.4.4 "Configuring Switches").
Note
This detection differs from the inverter detection in that it does not proceed according
to the principle of the search, but a device is set up for every defined switch.
After they have been detected and configured, the switches are available in the
Configuration | Smart Energy | Switch groups

23.2 Smart Energy Switching Groups

There are two tabs under
•
Switching groups
•
Surplus management
Switching groups
The menu is divided into the following sub-sections:
•
Hardware
All of the detected switches are displayed in this section.
•
Switching groups
The switch contacts for the switching groups can be added in this section and new switching
groups can be created and configured. Switching contacts in the switching groups are activated
by the Solar-Log™. Unassigned contacts are only recorded – as long as the values can be recorded
(depends on the hardware).
Up to 10 groups are available. Up to eight contacts can be assigned to each group.
and can be assigned to switch groups.
Configuration | Smart Energy
OK
.
Hardware
:
Smart Energy
section under
