Connecting accessories
Note!
Note!
Relay output assignments
Fig.: Smart Relay Box relay output (change-over contact) diagram
Fig.: Smart Relay Box relay output (make contact) diagram
58
The Solar-Log™ Smart Relay Box cannot be connected together with inverters on an
RS485 interface. The Relay Box requires its own separate RS485 bus.
It is possible to combine the Utility Meter with sensors.
The Solar-Log™ Smart Relay Box cannot be connected together with PM+ packages on a
Solar-Log™.
