PanoVu Mini Series
Network PTZ Camera
User Manual

Advertisement

Table of Contents
loading

Related Manuals for HIKVISION PanoVu Mini Series

Summary of Contents for HIKVISION PanoVu Mini Series

  • Page 1 PanoVu Mini Series Network PTZ Camera User Manual...
  • Page 2 SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
  • Page 3 User Manual of Network PTZ Camera IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. 0504121080517 © Hikvision...

  • Page 4: Regulatory Information

    This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements. Waring: This is a class A product. In a domestic environment this product may cause radio inter-ference in which case the user may be required to take adequate measures. © Hikvision...

  • Page 5: Safety Instruction

     Make sure the power supply voltage is correct before using the product.  Do not drop the product or subject it to physical shock. Do not install the product on vibratory surface or places.  Do not expose it to high electromagnetic radiating environment. © Hikvision...
  • Page 6  Use a soft and dry cloth when clean inside and outside surfaces of the product cover. Do not use alkaline detergents.  Improper use or replacement of the battery may result in hazard of explosion. Use the manufacturer recommended battery type. © Hikvision...

  • Page 7: Table Of Contents

    Configuring Alarm Input ....................39 5.2.4 Configuring Alarm Output ....................40 5.2.5 Handling Exception ......................41 ..................... 42 MART VENT ONFIGURATION 5.3.1 Detecting Audio Exception ....................42 5.3.2 Configuring Intrusion Detection ..................44 5.3.3 Configuring Line Crossing Detection .................. 45 © Hikvision...
  • Page 8 Configuring Privacy Mask ....................79 6.3.5 Configuring Image Parameters Switch................80 ....................81 ONFIGURING YSTEM ETTINGS 6.4.1 System Settings ........................81 6.4.2 Maintenance ........................84 6.4.3 Security ..........................86 6.4.4 User Management ......................88 APPENDIX SADP S ......................93 OFTWARE NTRODUCTION © Hikvision...

  • Page 9: Chapter 1 Overview

    At telephoto zoom settings, the pan and tilt speeds will be slower than at wide zoom settings. This keeps the image from moving too fast on the live view image when there is a large amount of zoom.  Auto Focus © Hikvision...
  • Page 10 Comparing with the general 2D digital noise reduction, the 3D digital noise reduction function processes the noise between two frames besides processing the noise in one frame. The noise will be much less and the video will be clearer. © Hikvision...

  • Page 11: Chapter 2 Network Connection

    Figure 2-1.  Refer to the Figure 2-2 to set the network camera over the LAN via a switch or a router. Network Cable Network PTZ Camera Computer Figure 2-1 Connecting Directly © Hikvision...

  • Page 12: Activating The Camera

    The password should be something of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product. © Hikvision...
  • Page 13  Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. © Hikvision...
  • Page 14 Get the client software from the supplied disk or the official website, and install the software according to the prompts. Follow the steps to activate the camera. Steps: Run the client software and the control panel of the software pops up, as shown in Figure 2-6. © Hikvision...
  • Page 15 Figure 2-7 Device Management Interface Check the device status from the device list, and select an inactive device. Click Activate to pop up the Activation interface. Create a password and input the password in the password field, and confirm the password. © Hikvision...
  • Page 16 Figure 2-9 Modifying the Network Parameters Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking Enable DHCP. Input the password to activate your IP address modification. © Hikvision...

  • Page 17: Setting The Network Camera Over The Wan

    You can also save the static IP in the camera and directly connect it to the internet without using a router. Refer to Section 2.1.2 for detailed IP address configuration of the camera. Network Network Cable Cable Internet Network PTZ Camera Figure 2-11 Accessing the Camera with Static IP Directly © Hikvision...

  • Page 18: Dynamic Ip Connection

     Normal Domain Name Resolution Steps: 1. Apply a domain name from a domain name provider. 2. Configure the DDNS settings in the DDNS Settings interface of the network camera. Refer to © Hikvision...
  • Page 19 User Manual of Network PTZ Camera Section 6.1.1 Configuring DDNS Settings for detailed configuration. 3. Visit the camera via the applied domain name. © Hikvision...

  • Page 20: Chapter 3 Accessing To The Network Camera

    6. Install the plug-in before viewing the live video and operating the camera. Follow the installation prompts to install the plug-in. You may have to close the web browser to install the plug-in. Reopen the web browser and log in again after installing the plug-in. © Hikvision...

  • Page 21: Accessing By Client Software

    The product CD contains the client software. You can view the live video and manage the camera with the client software. Follow the installation prompts to install the client software and WinPcap. The configuration interface and live view interface of client software are shown in Figure 3-3. Figure 3-3 iVMS-4200 Control Panel © Hikvision...
  • Page 22 If you use third party VMS software, contact technical support of our branch for camera firmware.  For detailed information about client software of our company, refer to the user manual of the software. This manual mainly introduces accessing to the network camera by web browser. © Hikvision...

  • Page 23: Chapter 4 Basic Operations

    HTTP: Allows the same quality as of TCP without setting specific ports for streaming under some network environments.  Play Performance: Set the live view performance to Shortest Delay, Balanced, or Fluent.  Rules: You can enable or disable the rules of dynamic analysis for motion here. © Hikvision...

  • Page 24: Live View Page

    Log in the network camera to enter the live view page, or you can click on the menu bar of the main page to enter the live view page. The functions vary depeding on different camera models. Refer to the actual interface as standard. © Hikvision...

  • Page 25: Starting Live View

    Configure the image size, stream type, plug-in type, and two-way audio of the live video. 4.3 Starting Live View In the live view window as shown in Figure 4-3, click on the toolbar to start the live view of the network. © Hikvision...
  • Page 26 . Then drag the mouse towards low right direction to draw a rectangle on the image as the desired zoom. After viewing it you can click any place of the picture to get back to normal picture. © Hikvision...

  • Page 27: Operating Ptz Control

    4.4.1 PTZ Control Panel On the live view page, click to show the PTZ control panel or click to hide it. Click the direction buttons to control the pan/tilt movements. Click the zoom/iris/focus buttons to realize lens control. © Hikvision...
  • Page 28 , the lens zooms in, click Zoom out/in , and the lens zooms out. Click , the lens focus far and the items far away gets clear. Click Focus far/near the lens focus near and the items nearby gets clear. © Hikvision...

  • Page 29: Auxiliary Functions

    The Auxiliary functions panel is shown in Figure 4-5. Figure 4-5 Auxiliary Functions  Light Click to enable/disable the light supplement of the camera. This function is reserved.  Wiper Click to move the wiper once.  Auxiliary Focus The auxiliary focus function is reserved. © Hikvision...

  • Page 30: Setting/Calling A Preset

    2. Use the PTZ control buttons to move the lens to the desired position. • Pan the camera to the right or left. • Tilt the camera up or down. • Zoom in or out. • Refocus the lens. 3. Click to finish the setting of the current preset. © Hikvision...
  • Page 31 The following presets are predefined with special commands. You can only call them but not configure them. Table 4-4 Special Presets Preset Function Preset Function Back to origin Set manual limits Day mode Save manual limits Night mode Remote reboot Figure 4-8 Special Preset © Hikvision...

  • Page 32: Playback

    Figure 4-10 Search Video Click to play the video files found on this date. The toolbar on the bottom of Playback interface can be used to control playing process. Figure 4-11 Playback Toolbar Table 4-5 Description of the buttons © Hikvision...

  • Page 33: Downloading Video Files

    Figure 4-14 Video Types 4.5.2 Downloading Video Files Steps: Click on the playback interface. The pop-up menu is shown in Figure 4-15. Set the start time and end time. Click Search. The corresponding video files are listed on the left. © Hikvision...
  • Page 34 User Manual of Network PTZ Camera Figure 4-15 Video Downloading interface Check the checkbox in front of the video files that you need to download. Click to download the video files. © Hikvision...

  • Page 35: Chapter 5 System Configuration

    Configuration > Storage > Schedule Settings > Record Schedule Figure 5-1 Recording Schedule Interface 2. Select the camera channel to configure. 3. Check Enable to enable scheduled recording. 4. To set the advanced settings of the camera, click to enter the advanced settings interface. © Hikvision...
  • Page 36 Motion Detection settings interfaces.  Record Triggered by Event: If you select to record by event, the video will be recorded when any of the events is triggered. 7. Click to save the settings. © Hikvision...

  • Page 37: Configuring Capture Schedule

    After setting the capture schedule, you can click a capture segment to display the segment capture settings interface to edit the segment capture parameters. (optional) Figure 5-4 Segment Snapshot Settings Click Advanced to enter the advanced setting interface. You can select the stream type of the capture. © Hikvision...

  • Page 38: Configuring Net Hdd

    The network disk should be available within the network and properly configured to store the recorded files, log files, etc. Steps:  Add the network disk 1. Enter NAS (Network-Attached Storage) settings interface: Configuration > Storage > Storage Management > Net HDD © Hikvision...
  • Page 39  Initialize the added network disk. 1. Enter HDD settings interface (Configuration > Storage > Storage Management > HDD Management), in which you can view the capacity, free space, status, type and property of the disk. © Hikvision...
  • Page 40 Figure 5-8 Quota Settings  Up to 8 NAS disks can be connected to the camera.  To initialize and use the memory card after insert it to the camera, refer to the steps of NAS disk initialization © Hikvision...

  • Page 41: Basic Event Configuration

    Select the Channel No. from the dropdown list. Set the Motion Detection Area. Check the Enable Motion Detection checkbox. Check the Enable Dynamic Analysis for Motion checkbox. Select the configuration mode as Normal or Expert and set the corresponding motion detection parameters.  Normal: © Hikvision...
  • Page 42 Figure 5-9 Motion Detection Settings-Normal Click Draw Area. Drag the mouse on the live view image to draw a motion detection area. Click Stop Drawing to finish drawing. iii. Move the slider to set the sensitivity of the detection.  Expert: © Hikvision...
  • Page 43 • Notify Surveillance Center: Send an exception or alarm signal to remote management software when an event occurs. • Send Email: Send an email with alarm information to a user or users when an event occurs. © Hikvision...
  • Page 44  Root directory: The files will be saved in the root of FTP server.  Parent directory: The files will be saved in a folder in FTP server. The name of folder can be defined as shown in Figure 6-9. © Hikvision...

  • Page 45: Configuring Video Tampering Alarm

    5.2.2 Configuring Video Tampering Alarm Purpose: You can configure the camera to trigger the alarm actions when the lens is covered. Steps: 1. Enter Video Tampering settings interface : Configuration > Event > Basic Event > Video Tampering © Hikvision...
  • Page 46 Refer to Section 5.2.1 Configuring Motion Detection. 8. Click tab to select the linkage method taken for tampering, notify surveillance center, and send email are selectable. Refer to Section 5.2.1 Configuring Motion Detection. 9. Click to save the settings. © Hikvision...

  • Page 47: Configuring Alarm Input

    6. You can also choose the PTZ linking for the alarm input. Check the relative checkbox and select the No. to enable Preset Calling, Patrol Calling or Pattern Calling. 7. You can copy your settings to other alarm inputs. 8. Click to save the settings. © Hikvision...

  • Page 48: Configuring Alarm Output

    5. Click tab to enter the arming schedule setting interface. The arming schedule configuration is the same as the setting of the arming schedule for motion detection. Refer to Section 5.2.1 Configuring Motion Detection. © Hikvision...

  • Page 49: Handling Exception

    The exception type can be HDD full, HDD error, and illegal login to the cameras. Steps: Enter Exception settings interface: Configuration > Event > Basic Event > Exception 2. Check the checkbox to set the actions taken for the exception alarm. Refer to Section 5.2.1 Configuring Motion Detection. © Hikvision...

  • Page 50: Smart Event Configuration

    The functions vary depending on different camera models. 5.3.1 Detecting Audio Exception Purpose: When you enable this function and audio exception occurs, the alarm actions will be triggered. Steps: Enter Audio Exception Detection interface: Configuration > Event > Smart Event > Audio Exception Detection © Hikvision...
  • Page 51 Refer to Section 5.2.1 Configuring Motion Detection. 6. Click tab to select the linkage method taken for the audio input exception, Notify Surveillance Center, Send Email, and Trigger Recording are selectable. Refer to Section 5.2.1 Configuring Motion Detection. Click to save the settings. © Hikvision...

  • Page 52: Configuring Intrusion Detection

    1) Select the Region No.in dropdown list. 2) Click to draw a rectangle on the image as a defense region. 3) Click on the image to specify a corner of the rectangle, and right-click the mouse after four corners are configured. © Hikvision...

  • Page 53: Configuring Line Crossing Detection

    4. The event triggered and park action related PTZ movement will be locked for 180 seconds after you enter the line crossing detection interface. Optionally, you can click the button to manually activate the movement, or lock the movement when the button turns to by clicking it. © Hikvision...
  • Page 54 Refer to Section 5.2.1 Configuring Motion Detection. 8. Click tab to select the linkage method taken for the line crossing detection, Notify Surveillance Center, Send Email, Upload to FTP/Memory Card/NAS, Trigger Recording © Hikvision...

  • Page 55: Ptz Configuration

    Proportional Pan: If you enable this function, the pan/tilt speeds change according to the amount of zoom. When there is a large amount of zoom, the pan/tilt speed will be slower for keeping the image from moving too fast on the live view image. © Hikvision...

  • Page 56: Configuring Ptz Limits

    3. Click to save the settings. 5.4.2 Configuring PTZ Limits Purpose: The camera can be programmed to move within the configurable PTZ limits (left/right, up/down). Steps: Enter Limit configuration interface: Configuration > PTZ > Limit © Hikvision...

  • Page 57: Configuring Initial Position

    The initial position is the origin of PTZ coordinates. It can be the factory default initial position. You can also customize the initial position according to your own demand.  Customize an Initial Position: Steps: Enter Initial Position configuration interface: Configuration > PTZ > Initial Position © Hikvision...

  • Page 58: Configuring Park Actions

    Scheduled Tasks function is prior to Park Action function. When these two functions are set at the same time, only the Scheduled Tasks function takes effect.  Park function varies depending on different camera models. Steps: 1. Enter Park Action settings interface: Configuration > PTZ > Park Action © Hikvision...

  • Page 59: Configuring Privacy Mask

    Privacy mask enables you to cover certain areas on the live video to prevent certain spots in the surveillance area from being live viewed and recorded. You can only configure privacy mask function for tracking PTZ camera. Steps: 1. Enter Privacy Mask settings interface: Configuration > PTZ > Privacy Mask © Hikvision...
  • Page 60 Active Zoom Ratio on your demand, and then the mask will only appear when the zoom ratio is greater than the predefined value. Figure 5-27 Privacy Mask List Check Enable Privacy Mask to enable this function. Click Save to save the settings. © Hikvision...

  • Page 61: Configuring Panorama Linkage

    1× is recommended. 5. Click Get PTZ Position, and the PTZ position is displayed in Calibration Parameter list. 6. Click Start Calibration. Repeat the steps above to add more calibration points for the selected panoramic camera channel. © Hikvision...

  • Page 62: Configuring Scheduled Tasks

    5. Select the timeline of a certain day, and drag the mouse to set the recording schedule (the start time and end time of the recording task). 6. After you set the scheduled task, you can click and copy the task to other days (optional). © Hikvision...

  • Page 63: Clearing Ptz Configuration

    Steps: 1. Enter Clearing Configuration interface: Configuration > PTZ > Clear Config 2. Check the checkbox of the items you want to clear. Figure 5-30 Clear Config 3. Click to clear the settings. © Hikvision...

  • Page 64: Chapter 6 Camera Configuration

    IPv6 are both supported. Steps: Enter TCP/IP settings interface: Configuration > Network > Basic Settings > TCP/IP Figure 6-1 TCP/IP Settings 2. Configure the NIC settings, including the IPv4(IPv6) Address, IPv4(IPv6) Subnet Mask and IPv4(IPv6) Default Gateway. © Hikvision...

  • Page 65: Configuring Ddns Settings

    Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. Steps: 1. Enter DDNS settings interface: Configuration > Network > Basic Settings > DDNS 2. Check Enable DDNS to enable this feature. © Hikvision...

  • Page 66: Configuring Pppoe Settings

    Configuring PPPoE Settings Purpose: If you have no router but only a modem, you can use Point-to-Point Protocol over Ethernet (PPPoE) function. Steps: Enter PPPoE settings interface: Configuration > Network > Basic Settings > PPPoE Figure 6-4 PPPoE Settings © Hikvision...

  • Page 67: Configuring Port Settings

    Server Port: The default port number is 8000. Click to save the settings. Configuring NAT (Network Address Translation) Settings Purpose: Universal Plug and Play (UPnP™) is a networking architecture that provides compatibility among networking equipment, software and other hardware devices. The UPnP protocol allows devices © Hikvision...

  • Page 68: Advanced Settings

    Before setting the SNMP, use the SNMP software and manage to receive the camera information via SNMP port. By setting the Trap Address, the camera can send the alarm event and exception messages to the surveillance center. The SNMP version you select should be the same as that of the SNMP software. © Hikvision...

  • Page 69: Configuring Ftp Settings

    The configuration of the SNMP software should be the same as the settings you configure here. 4. Click to save and finish the settings. Configuring FTP Settings Purpose: You can set a FTP server and configure the following parameters for uploading captured pictures. © Hikvision...
  • Page 70  Root directory: The files will be saved in the root of FTP server.  Parent directory: The files will be saved in a folder in FTP server. The name of folder can be defined as shown in Figure 6-9. Figure 6-9 Parent Directory © Hikvision...

  • Page 71: Configuring Email Settings

    Configure the DNS Server settings under Configuration> Network > Basic Settings > TCP/IP before using the Email function. Steps: 1. Enter Email settings interface: Configuration> Network > Advanced Settings > Email Figure 6-11 Email Settings 2. Configure the following settings: © Hikvision...
  • Page 72 Platform access provides you an option to manage the devices via platform. Steps: 1. Enter Platform settings interface: Configuration> Network > Advanced Settings > Platform Access 2. Check the checkbox of Enable to enable the platform access function of the device. © Hikvision...

  • Page 73: Configuring Https Settings

    Configuration > Network > Advanced Settings > HTTPS 2. Create the self-signed certificate or authorized certificate. Figure 6-12 Create Certificate OPTION 1: Create the self-signed certificate Select Create Self-signed Certificate. Click Create to create the following dialog box. © Hikvision...
  • Page 74 Figure 6-14 Installed Certificate Property  The default port number of HTTPS is 443. The port value ranges from 1 to 65535.  When the port number is the default number 443, the format of the URL is https://IP address, eg., https://192.168.1.64. © Hikvision...

  • Page 75: Configuring Qos Settings

    IEEE 802.1X is a port-based network access control. It enhances the security level of the LAN. When devices connect to this network with IEEE 802.1X standard, the authentication is needed. If the authentication fails, the devices don’t connect to the network. The protected LAN with 802.1X standard is shown in Figure 6-16. © Hikvision...
  • Page 76 Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. Steps: Connect the network camera to your PC directly with a network cable. Enter 802.1X settings interface: Configuration > Network > Advanced Settings > 802.1X Figure 6-17 802.1X Settings © Hikvision...

  • Page 77: Configuring Video And Audio Settings

    Refer to the Section 4.1 Configuring Local Parameters for switching the main stream and sub-stream for live viewing. Sub-stream is not supported by certain camera models. © Hikvision...

  • Page 78: Configuring Audio Settings

    The lower value of the smoothing, the higher quality of the stream, though it may appear not fluent. 5. Click to save the settings. 6.2.2 Configuring Audio Settings Steps: 1. Enter Audio settings interface Configuration > Video/Audio > Audio © Hikvision...

  • Page 79: Configuring Roi Settings

    When Fixed Region is enabled, image quality of ROI area will be enhanced and image quality of other areas will be reduced. ROI function varies depending on different camera models. Enter ROI settings interface: Configuration >Video/Audio > ROI © Hikvision...
  • Page 80 The number of areas supported in ROI function varies depending different camera models Select the Region No. from the dropdown list. Adjust the ROI level from 1 to 6. The higher the value, the better image quality in the red frame. Enter a Region Name. Click to save the settings. © Hikvision...

  • Page 81: Display Info. On Stream

    1. Enter Display Settings interface: Configuration > Image> Display Settings 2. Select the camera channel to configure. 3. You can select the Scene from the dropdown list with different predefined image parameters. 4. Set the image parameters of the camera. © Hikvision...

  • Page 82: Image Adjustment

    In Manual mode, you can adjust the values of Shutter, Gain, and Limit Gain manually. Focus Settings  Focus Mode The Focus Mode can be set as Manual, and Semi-auto.  Semi-auto: The camera focuses automatically only once after panning, tilting and zooming. © Hikvision...
  • Page 83 When there are both very bright and very dark areas simultaneously in the field of view, WDR balances the brightness level of the whole image and provide clear images with details. You can enable or disable the WDR function. The wide dynamic level ranges from 0 to 100. © Hikvision...

  • Page 84: White Balance

    3D Digital Noise Reduction You can set Digital Noise Reduction function to Normal and adjust the Noise Reduction Level as shown in Figure 6-25. The level ranges from 0 to 100. Figure 6-25 3D Digital Noise Reduction-Normal Mode © Hikvision...

  • Page 85: Configuring Osd Settings

    The lens operates the movements for initialization when you enable Lens Initialization.  Zoom Limit You can set Zoom Limit value to limit the maximum value of zooming. The value can be selected from the list. 6.3.2 Configuring OSD Setting Purpose: Configure the following on screen displays. Steps: © Hikvision...

  • Page 86: Configuring Text Overlay Settings

    2. Check the checkbox in front of textbox to enable the on-screen display. 3. Input the characters in the textbox. 4. Use the mouse to drag the red text frame in the live view window to adjust the text overlay position. 5. Click to save the settings. © Hikvision...

  • Page 87: Configuring Privacy Mask

    Drag the mouse in the live view window to draw the mask area. Click Stop Drawing to finish drawing or click Clear All to clear all of the areas you set without saving them. Click to save the settings. Figure 6-28 Configuring Privacy Mask © Hikvision...

  • Page 88: Configuring Image Parameters Switch

    Figure 6-30 Linked Scene 4. When you enable the function of Scheduled-Switch, check the corresponding checkbox, set the time period and the linked scene. Figure 6-31 Schedule-Switch 5. Click to save the settings. The two functions are not enabled by default. © Hikvision...

  • Page 89: Configuring System Settings

    There are Time Zone, Time Synchronization, and Daylight Saving Time (DST) functions for setting the time. Time Synchronization consists of auto mode by Network Time Protocol (NTP) server and manual mode. Enter Time Settings interface: Configuration > System > System Settings > Time Settings © Hikvision...
  • Page 90 NTP server for time synchronization.  Configuring Time Synchronization Manually Steps: (1) Check the Manual Time Sync radio button. (2) Click to set the system time from the pop-up calendar. (3) Click to save the settings. © Hikvision...
  • Page 91 If there is the habit of adjusting clocks forward in your country in certain time period of a year, you can turn this function on. The time will be adjusted automatically when the Daylight Saving Time (DST) comes. Steps: 1. Enter DST settings interface Configuration > Advanced Configuration > System > DST Figure 6-37 DST Settings © Hikvision...

  • Page 92: Maintenance

    Set the saving path to save the configuration file in local storage. Click Diagnose Information to download the log and system information.  Importing Configuration File Enter Maintenance interface: Configuration > System > Maintenance > Upgrade & Maintenance © Hikvision...

  • Page 93: Upgrading The System

    The operation, alarm, exception and information of the camera can be stored in log files. You can also export the log files on your demand. Before you start: Configure network storage for the camera or insert a memory card in the camera. Steps: 1. Enter Log interface: Configuration >System > Maintenance > Log © Hikvision...

  • Page 94: Security

    4. Check or uncheck Enable Sub Stream to enable/disable the sub-stream. 5. Click to save the settings. 6.4.3 Security Configuring Authentication Security Purpose: You can specifically secure the stream data of live view via authentication configuration. RTSP authentication and WEB authentication are supported. © Hikvision...
  • Page 95 3. Select the type of IP Address Filter in the dropdown list, Forbidden and Allowed are selectable. 4. Set the IP Address Filter list.  Add an IP Address Steps: (1) Click Add to add an IP. (2) Input the IP Adreess. © Hikvision...

  • Page 96: User Management

    Click to save the settings. 6.4.4 User Management Enter User Management interface: Configuration > System > User Management The admin user has access to create, modify or delete other accounts. Up to 32 user accounts can be created. © Hikvision...
  • Page 97 The level indicates the permissions you give to the user. You can define the user as Operator or User. In the Basic Permission field and Camera Configuration field, you can check or uncheck the permissions for the new user. Click to finish the user addition. © Hikvision...
  • Page 98 1. Left-click to select the user from the list and click 2. Modify the User Name, Level or Password. 3. In the Basic Permission field and Camera Configuration field, you can check or uncheck the permissions. 4. Click to finish the user modification. © Hikvision...

  • Page 99: Online Users

    1. Left-click the user name you want to delete and click 2. Click on the pop-up dialogue box to delete the user. Online Users Enter Online Users configuration interface: Configuration > System > User Management > Online Users © Hikvision...
  • Page 100 You can see the current users who are visiting the device through this interface. User information, such as user name, level, IP address, and operation time, is displayed in the User List. Click Refresh to refresh the list. © Hikvision...

  • Page 101: Appendix

    Search online devices manually You can also click to refresh the online device list manually. The newly searched devices will be added to the list. You can click on each column heading to order the information; you can © Hikvision...
  • Page 102  Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. Figure A.1.2 Modify Network Parameters © Hikvision...
  • Page 103 UD10058B...
