- Page 1 PanoVu Series Camera Quick Start Guide UD01546B...
- Page 2 SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
- Page 3 PanoVu Series Camera·Quick Start Guide Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 PanoVu Series Camera·Quick Start Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Warnings and Cautions: Warnings: Neglecting any of the warnings may cause serious injury or death.
- Page 5 PanoVu Series Camera·Quick Start Guide Exposing the equipment to direct sun light, low ventilation or heat source such as heater or radiator is forbidden (ignorance can cause fire danger). Do not aim the panoVu camera at the sun or extra bright places. A blooming or smear may occur otherwise (which is not a malfunction however), and affecting the endurance of sensor at the same time.
-
Page 6: Table Of Contents
PanoVu Series Camera·Quick Start Guide Table of Contents 1 Installation ....................6 1.1 Connecting Cables ........................6 1.2 Alarm Input and Output Connection ..................7 2 Mounting Application .................. 8 2.1 Installing the Bracket ........................ 8 2.1.1 Installing the Wall Mounting Bracket ................. 8 2.1.2 Installing the Hoop Mounting Bracket ................ -
Page 7: Installation
Alarm Outputs Alarm Inputs Optical FC Interface Network Cable Figure 1-1 Cables of PanoVu Series Camera The cables may vary according to the models. Use the power adapter that can work normally at an altitude over 5000 meters above sea... -
Page 8: Alarm Input And Output Connection
PanoVu Series Camera·Quick Start Guide 1.2 Alarm Input and Output Connection The network camera can be connected with alarm inputs (0~5VDC) Refer to the following diagrams for alarm output: JQC- 3FG GND OUT Relay DC Load ( 10 A 250VAC) 30VDC ～220V AC... -
Page 9: Mounting Application
PanoVu Series Camera·Quick Start Guide 2 Mounting Application Before you start: For cement wall, you need to use the expansion screw to fix the bracket. The mounting hole of the expansion pipe on the wall should align with the mounting hole on the bracket. -
Page 10: Installing The Hoop Mounting Bracket
PanoVu Series Camera·Quick Start Guide Figure 1-4 Drill Screw Hole and Insert Expansion Screw Secure the bracket with 4 hex nuts and washers. Figure 1-5 Drill Screw Holes Please take water-proof measures when installing outdoor PanoVu Camera. 2.1.2 Installing the Hoop Mounting Bracket ... - Page 11 PanoVu Series Camera·Quick Start Guide Pendent Bracket Hoop Bracket Figure 1-6 Hoop Bracket and Pendent Bracket Fix the hoop to the pole by adjusting the hoop according to the pole, as shown in Figure 1-7. Fixing Plate Towards the Ground Figure 1-7 Drill Hole and Insert Expansion Screws Fix the hoop bracket with the pendent bracket.
-
Page 12: Installing The Panovu Camera
PanoVu Series Camera·Quick Start Guide 2.2 Installing the PanoVu Camera The appearance of PanoVu camera may vary according to the models. The appearance shown below is only for reference. 2.2.1 Installing the 180° Panoramic + PTZ Camera Steps: Loosen the two lock screws on the both side of the camera. Pull the lower camera to separate it from the back box as shown in Figure 1-9. - Page 13 PanoVu Series Camera·Quick Start Guide Figure 1-11 Micro SD Card Slot Separate the head cover from the camera main body, as shown in Figure 1-12. Head Cover Camera Main Body Figure 1-12 Head Cover of PanoVu Camera Install the head cover of PanoVu camera.
-
Page 14: Installing The 360° Panoramic + Ptz Camera
PanoVu Series Camera·Quick Start Guide Safety Rope V I E O D Figure 1-14 Install the Safety Rope Connect all cables and insert the rest cables into the bracket. Fix the PanoVu camera with the head cover by fixing screws of the head cover and bracket, as shown in Figure 1-15. - Page 15 PanoVu Series Camera·Quick Start Guide Back Box Lens Cover Lower Dome Protective Foam Figure 1-16 Remove the Lower Camera Remove the protective foam, sticker and lens cover from the camera drive. As shown in Figure 1-17. Sticker Figure 1-17 Remove the Sticker Install the micro SD card.
- Page 16 PanoVu Series Camera·Quick Start Guide Head Cover Camera Main Body Figure 1-19 Head Cover of PanoVu Camera Install the head cover of PanoVu camera. 1) Loosen the two lock screws and make sure that the screws do not appear in the inner side of bracket, as shown in Figure 1-20.
-
Page 17: Installing The 360° Panoramic Camera
PanoVu Series Camera·Quick Start Guide Connect all cables and insert the rest cables into the bracket. Fix the PanoVu camera with the head cover by fixing screws of the head cover and bracket, as shown in Figure 1-22. Figure 1-22 Fix the PanoVu Camera 2.2.3 Installing the 360°... - Page 18 PanoVu Series Camera·Quick Start Guide 2) Insert the matched micro SD card until the card slot clicks. 3) Put the cover back on the camera. Install the head cover of PanoVu camera. 1) Loosen the two lock screws and make sure that the screws do not appear in the inner side of bracket, as shown in Figure 1-25.
- Page 19 PanoVu Series Camera·Quick Start Guide Figure 1-27 Fix the PanoVu Camera...
-
Page 20: Setting The Camera Over The Lan
PanoVu Series Camera·Quick Start Guide 3 Setting the Camera Over the LAN You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. -
Page 21: Activation Via Sadp Software
PanoVu Series Camera·Quick Start Guide The default IP address of the panoVu camera is 192.168.1.64. Figure 3-2 Activation Interface(Web) Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED–We highly recommend you create a strong password of your own choosing (Using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase the security of your product. -
Page 22: Modifying The Ip Address
PanoVu Series Camera·Quick Start Guide Figure 3-3 SADP Interface Create a password and input the password in the password field, and confirm the password. STRONG PASSWORD RECOMMENDED–We highly recommend you create a strong password of your own choosing (Using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase the security of your product. - Page 23 PanoVu Series Camera·Quick Start Guide Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Figure 3-4 Modify the IP Address Input the password and click Save to activate your IP address modification.
-
Page 24: Accessing Via Web Browser
PanoVu Series Camera·Quick Start Guide 4 Accessing via Web browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher... - Page 25 PanoVu Series Camera·Quick Start Guide Figure 4-2 Download Plug-in Figure 4-3 Install Plug-in 6. Reopen the web browser after the installation of the plug-in and repeat the above steps 2-4 to login. For detailed instructions of further configuration, please refer to the user manual of network panoVu camera.
- Page 26 PanoVu Series Camera·Quick Start Guide...
