- Page 1 IR Network Speed Dome Quick Guide...
- Page 2 IR High-Definition Network Speed Dome·Quick Guide Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual applies to IR High-Definition Network speed dome. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice.
- Page 3 IR High-Definition Network Speed Dome·Quick Guide Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 IR High-Definition Network Speed Dome·Quick Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Warnings and Cautions: Warnings: Neglecting any of the warnings may cause serious injury or death. Cautions: Neglecting any of the cautions may cause injury or equipment damage.
- Page 5 IR High-Definition Network Speed Dome·Quick Guide Exposing the equipment to direct sun light, low ventilation or heat source such as heater or radiator is forbidden (ignorance can cause fire danger). Do not aim the speed dome at the sun or extra bright places. A blooming or smear may occur otherwise (which is not a malfunction however), and affecting the endurance of sensor at the same time.
- Page 6 IR High-Definition Network Speed Dome·Quick Guide Table of Contents 1 Overview ........................6 2 Installation ........................ 7 3 Setting the Network Dome over the LAN ..............10 4 Accessing via Web Browser ..................13...
-
Page 7: Overview
IR High-Definition Network Speed Dome·Quick Guide 1 Overview Please make sure the power of the speed dome has been disconnected before connecting the cables. The cable interfaces of network speed dome are shown in following figure (left). The cables are distinguished by different colors. The labels attached on the cables are for identification. -
Page 8: Installation
IR High-Definition Network Speed Dome·Quick Guide 2 Installation Before you start: Check the package contents and make sure that the device in the package is in good condition and all the assembly parts are included. Please make sure the wall is strong enough to withstand more than 8 times the weight of the dome and the mount. - Page 9 IR High-Definition Network Speed Dome·Quick Guide Figure 2-2 Secure the Mount Notes: The mount in Figure 2-2 is the recommended mount for this series of speed dome, and a pendent adapter is required if any other mount is selected. See Figure 2-3. ...
- Page 10 IR High-Definition Network Speed Dome·Quick Guide Lock Screw Safety Rope Figure 2-4 Secure the Speed Dome...
-
Page 11: Setting The Network Dome Over The Lan
IR High-Definition Network Speed Dome·Quick Guide 3 Setting the Network Dome over the LAN To view and configure the speed dome via LAN (Local Area Network), you need to connect the network speed dome in the same subnet with your PC. Then, install the SADP or the client software to search and change the IP of network speed dome. - Page 12 IR High-Definition Network Speed Dome·Quick Guide Figure 3-2 Search Online Devices Note: Device can be searched and displayed in the list in 15 seconds after it goes online; it will be removed from the list in 45 seconds after it goes offline. Search online devices manually: You can also click to refresh the online device list manually.
- Page 13 IR High-Definition Network Speed Dome·Quick Guide Figure 3-3 Select a Device Figure 3-4 Modify Network Parameters Enter the IP address of network speed dome in the address field of the web browser to view the live video. Notes: The default value of the IP address is 192.0.0.64. The default user name of administrator is admin, and password is 12345.
-
Page 14: Accessing Via Web Browser
IR High-Definition Network Speed Dome·Quick Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 7.0 and above version, Apple Safari 5.02 and above... - Page 15 IR High-Definition Network Speed Dome·Quick Guide Figure 4-2 Download Plug-in Figure 4-3 Install Plug-in 6. Reopen the web browser after the installation of the plug-in and repeat the above steps 2-4 to login. Note: For detailed instructions of further configuration, please refer to the user manual of network dome.
