Choose the drive to view then tap the ENGAGE icon. The 'DRIVE STATUS' for the selected drive
will change to "ENGAGED" and the ENGAGE icon will change to DISENGAGE. At this point,
connect a USB cable between the computer and the Talon Ultimate.
Connect a USB 3.0 cable (A Male to Micro B Male USB cable, one was included with the Talon
Ultimate) between the computer and the Talon Ultimate. Connect the micro USB B connector to
the Talon Ultimate's USB Device Port located on the front of the Talon Ultimate. Connect the USB
A connector to an available USB port on the computer.
After a few moments, Windows should assign a drive letter to the selected drive. The contents of
the drive should now be accessible in Windows.
When finished, tap the DISENGAGE icon to disengage the USB mode. The USB cable can now be
disconnected from the computer and the Talon Ultimate.
Only one drive can be
engaged at a time.

5.5.1 Settings

If the drive is not mounting properly, go to the Settings tab and change each
setting one at a time, then disengage and re-engage the drive.
This tab shows advanced settings for when the Operating System of the
computer the Talon Ultimate is connected to will not detect the drive properly.
If the drive is not detected by the Operating System, change the Export Mode
and/or the Export type. These settings will not change anything on the drive. It
will simply change how the Operating System sees or treats the connected drive.
Drives will still be write-protected.
