2.1 Turning the Talon Ultimate on and off

The Talon Ultimate comes with a 12V grounded, 11.5A (output DC) power supply that connects to
the back of the device. Attach the included power supply to the Talon Ultimate's DC power port in
the back.
To turn the Talon Ultimate on, press and immediately release the power button located on the
top right corner of the Talon Ultimate. The Talon Ultimate will turn on and start the boot process.
It is normal for the fans to either turn off or
slow down after the initial start-up sequence.
There are two ways of turning the Talon Ultimate off:
1. Press and immediately release the power button on the top right corner of the Talon
Ultimate. The Talon Ultimate will begin its shut down process and after a few seconds, the
display and fans will turn off.
2. Using the Graphical User Interface (GUI) either on the touch screen or via a browser
through a remote connection, navigate to the Power Off screen and tap or click the
Power Off icon.

2.2 Connecting various drive types

Cables and adapters are available for the following drive types:
SATA
•
USB
•
2.5" and 3.5" PATA/IDE
•
FireWire
•
SAS (SAS support is a software option)
•
1.8" micro SATA (optional)
•
1.8" ZIF (optional)
•
1.8" PATA/IDE (optional)
•
eSATA (optional)
•
mSATA (optional)
•
Flash Media (optional)
•
M.2 (optional)
•
PCIe (optional)
•

2.2.1 Connecting Source Drives

Source drives (also called suspect drives) must be connected to the left side of
the Talon Ultimate. These ports are write-protected and are labeled as follows:
•
Logicube Talon Ultimate™ User's Manual
SAS S1 – SAS/SATA data port for the Source 1 (S1) position. Optional
support for SAS drives requires additional software activation.
