Hash / Verify - Logicube Talon Ultimate User Manual

3.2 Hash / Verify

A hash or verify operation can be performed to any drive or case (DD, E01,
EX01, or DMG). Performing a hash or verify task will instruct the Talon Ultimate
to calculate the hash for the specified drive or case. There are two modes
available:
Details on the different screens found in the Hash/Verify
operation can be found in
DRIVE HASH – This mode will hash any connected drive on an active Source or
•
Destination port. This mode is Logical Block Address (LBA) based and will hash drives
based on the number of LBAs. If multiple drives are selected to be hashed, the Talon
Ultimate will hash up to the LBA value of the smallest capacity drive. If drives with
different capacities need to be hashed, it is recommended to start one task per drive.
CASE VERIFY – This mode will hash cases/images created by the Talon Ultimate (DD, E01,
•
Ex01, DMG) for verification purposes. There are two settings for this mode:
Primary – This will verify the primary hash of the image (SHA-1).
o
Both – This will verify both primary (SHA-1) and second hash (MD5) of the image.
o
Logicube Talon Ultimate™ User's Manual
After selecting the next Destination/Repository to be used, tap
the OK icon.
If the next Destination drive selected requires
formatting, the Talon Ultimate will show the
(format) icon allowing the drive to be formatted.
When the imaging operation is finished, all
subsequent Destinations/Repositories used will
contain the same Case/File name and the next
DD, E01, EX01, or DMG file. For example, if the
last file on the first Destination used is *.E23, the
next Destination/Repository used will start with
file *.E24.
Section 5.2: Hash/Verify.
To perform more than one task at a time
(Image, Hash, Wipe/Format), the Multi-Task
Option must be purchased and installed.
QUICK START
21
