9.0 Remote Operation - Introduction

The Talon Ultimate comes with a gigabit network connection in the back of the unit. Connecting
the Talon Ultimate to a network allows remote access to the Talon Ultimate from any computer
within the same network.
The Talon Ultimate is configured for DHCP by default. See
how to configure the Talon Ultimate with a Static IP address.
The Talon Ultimate is setup with a Zero Configuration Network (Zeroconf). There are two ways to
access the Talon Ultimate:
Web interface – A graphical interface using an Internet browser where the screens are
•
shown exactly the way they appear on the Talon Ultimate
Command Line Interface (CLI) – A text only command line interface that can be accessed
•
one of two ways:
i. Telnet (via a network connection)
ii. SSH (Secure Shell via a network connection)
BROWSER COMPATIBILITY: Google Chrome and
Mozilla Firefox are recommended. Other browsers may
not display the Graphical User Interface (GUI) properly.

9.1 Web Interface

Using a web browser, go to the IP address or the name of the Talon Ultimate with its serial
number. Both IP address and serial number can be found by going to the Statistics screen on the
Talon Ultimate. For example, browse to
XXXXXX is the 6-digit serial number of the Talon Ultimate. The Talon Ultimate's web interface will
appear on the browser screen. All screens and operations available on the Talon Ultimate will be
available on the browser.
On some browsers or Operating Systems, the Talon Ultimate will
need to be accessed by browsing to http://talon-XXXXXX.local.
The Talon Ultimate can be controlled by clicking on the icons appearing on the browser window.
Ultimate User's Manual
®
Logicube Talon
Section 5.11.1.1
http://192.168.1.100 or http://talon-XXXXXX

9: Remote Operation

for instructions on
where
110
