AIAG
Default identifiers for ID1 through ID12 are as follows:
ID1 ID2 ID3 ID4 ID5a ID5b
N P Q V S
The following rules apply:
1. Number of Symbols <KLnumber> must be set to the number of AIAG symbols
required per read cycle. (The number of AIAG IDs enabled has no effect.)
2. Any noread messages will be added to the end of the output with no ID prefix. For
example, the following symbols—S123, N456, P678, and Q987—are scanned in
order but the third symbol P678 fails to be decoded. The noread output will
appear at the end of the data array, as follows: S123,N456,Q987,NOREAD.
3. Symbol output is not sorted.
Allows any number of symbols with same ID if the data field is different.
MS-820 Industrial Bar Code Scanner User's Manual
5-22
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
ID5c ID6 ID7 ID8 ID9
M G H EZ EB ED
ID10 ID11 ID12
EC EL EX
