Laser Framing

Laser Framing
To adjust laser framing, click the
or down as shown here.
Usage: This is useful to avoid highly reflective objects, for filtering out unwanted
signals, and avoiding the wrong symbols.
Definition: Sets the percentage of time the laser is ON during each scan so that only
a selected portion of the scan width is effectively scanned.
When Laser Framing is disabled, the laser is ON during the full scan arc.
Serial Cmd: <KClaser on/off
position>
Default: Disabled
Check this to enable
Laser Framing

Figure 9-1 Laser Framing

MS-820 Industrial Bar Code Scanner User's Manual
9-4
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Laser Control button, and Laser On/Off
status,laser framing status,laser on position,laser off
Use your cursor to adjust the start
position for Laser Framing
Use your cursor to adjust the end
position for
arrows up
Laser Framing
