Table 4-1 Maximum Number of Characters by Number of Symbols ......... 4-3
Table 11-1 Summary of Utility Serial Commands .................................... 11-3
Table 11-2 Maximum Characters for Master Symbol Database ............ 11-13
Table 11-3 Hex Value to Binary Conversion .......................................... 11-20
Table 11-4 Scanner Status .................................................................... 11-20
Table A-1 MS-820 Status Lights ................................................................ A-3
Table A-2 MS-820 Host Connector, 15-pin ................................................ A-6
Table A-3 Host 25-pin Connector ............................................................ A-10
Table A-4 Trigger 4-pin Connector .......................................................... A-10
Table A-5 Power 3-pin Connector ........................................................... A-10
Table A-6 Scanner 15-pin Connector ...................................................... A-10
Table A-7 Network 25-pin Connector ...................................................... A-10
Table A-8 Complete List of Serial Configuration Commands .................. A-13
Table A-9 ASCII Table with Control Characters ...................................... A-18
Table A-10 Communication Protocol Commands .................................... A-19
Table A-11 Multidrop Addresses ............................................................. A-36
About the 820 Scanner
The MS-820 scanner can decode high density bar code symbols from 3 to 30 inches. Its
IP65 and heavy industrial rating makes it ideal for applications such as conveyors,
assembly lines, or embedding within machinery.
Its application code resides in an onboard flash memory chip that can be easily updated
1
by downloads. A user interface program, the ESP (Easy Setup Program), can be down-
loaded from our web site (www.microscan.com) and runs on Microsoft Windows 98,
Windows NT, Windows 2000, or Windows XP operating systems.
Alternately, configuration commands can be sent from an embedded, menu-driven
terminal program, or directly by host serial command strings.
1. See your Microscan sales representative to access the latest application codes.
