Multidrop
This setup allows the user to
link multiple scanners
together, using only one host.
IB-131: 99-000018-01
(1 per MS-820)
Multidrop Cable: 61-100030-03
(connects multiple IB-131s)
Power Supply: 97-100004-15
(for each scanner)
Trigger: 99-000017-01 (for
each scanner)
Daisy Chain
This setup allows the user to
link multiple scanners
together, using only one host.
IB-131: 99-000018-01
(1 per MS-820)
Daisy Chain Cable: 61-100029-03
(connects multiple IB-131s)
Power Supply: 97-100004-15
(for each scanner)
Trigger: 99-000017-01
(for each scanner)
MS-820 Industrial Bar Code Scanner User's Manual
A-12
