Step 4 Select Scanner Model - Microscan MS-820 User Manual

Step 4 — Select Scanner Model
When you start the program, the following menu will appear:
Note: If you need to select another model later, you can find it in the App Mode under
Model on the menu bar.
1. In the Model dialog box, select your model.
If you do not want to make this selection every time you load ESP, uncheck Show
this window at Startup.
2. Select the default name, for example MS-820-1, or type in a file name of your
choice and click OK.
3. Click Yes when the connect to the scanner dialog appears.
MS-820 Industrial Bar Code Scanner User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Chapter 1 Quick Start
1-5
