Step 6 — Position Symbol and Scanner
1
1. Set up a bar code symbol
2
application.
2. Avoid bright light or IR light from other sources, including other scanners.
3. Pitch symbol or scanner a minimum of ±15° to avoid specular reflection, the
return of direct, non-diffused light.
Skew
axis
Bar code
label
Scanner
Scan line

Figure 1-3 Symbol/Scanner Position

4.
Code 39 is the default symbol type enabled. If you are uncertain as to your symbology
type, enable all codes (see "Autodiscriminate" on page
1. If using an I 2/5 symbol, verify that the number of characters in the symbol being scanned
matches the symbol length enabled for the I 2/5 symbol type (default is 10 and 6). See
leaved 2 of 5" on page 5-11.
2. Consult "LED Indicators" on page
MS-820 Industrial Bar Code Scanner User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Chapter 1 Quick Start
at the scanning distance you will be using in your
Tilt
axis
Pitch
axis
5-26).
A-3.
"Inter-
1-7
